Lithium Grey

Viper Red

Rail+ 5 is an alloy enduro e-bike that delivers huge value for big adventures. Its rugged Alpha Platinum Aluminum frame partners with a RockShox Deluxe Select+ RT shock and Psylo Gold RC fork (160mm rear/front) to charge through the roughest terrain on the mountain. A Shimano Deore 12-speed drivetrain and 4-piston MT4100 brakes deliver clean shifting and brake modulation that doesn't break the bank. It's topped with a TranzX dropper post and tubeless-ready Bontrager Line TLR 30 wheels for charging into anything.

Trek Rail+ 5 Gen 5

This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

Dark Star

Powersurge

Rail+ 8 is an aluminum enduro e-bike with big power and tons of travel for wild, ride-anything adventures. It starts with an Alpha Platinum Aluminum frame paired with a RockShox Super Deluxe+ shock and ZEB Select fork (160mm front/rear) for making quick work of chunky backcountry rock gardens. You get the smooth-shifting performance of a Shimano XT/SLX drivetrain, stop-on-a-dime control from SRAM DB 8 4-piston disc brakes, a Bontrager Line dropper post, and tubeless-ready Bontrager Line TLR 30 wheels.

Trek Rail+ 8 Gen 5

Navy Smoke

Slate

Rail+ 9.7 is a carbon enduro e-MTB built for your biggest adventures. Its rugged OCLV Mountain Carbon frame delivers 160mm front and rear travel from a RockShox Zeb Select fork and Super Deluxe Select+ RT shock, making rowdy lines and root lattices a walk in the park. You get a Shimano XT/SLX drivetrain for 12-speed shifting you can count on, SRAM DB 8 4-piston brakes, a Bontrager Line dropper post, and Bontrager Line TLR tubeless-ready wheels for rolling into anything.

Trek Rail+ 9.7 Gen 5

The Rail+ 9.8 is a carbon enduro e-MTB made for chasing after distant peaks and hammering out laps. With 160 mm front and rear travel, it's ready to rip through the rough, and it's backed by a powerful Bosch Performance CX drive system that makes long climbs and fast laps a breeze. It packs in adjustable geometry that lets you customise your bike for how and where you ride, a massive battery that keeps you going lap after lap, and a Shimano XT drivetrain that keeps shifts clean and reliable.

Trek Rail+ 9.8 XT Gen 5

This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb).

Deep Smoke

Pennyflake

Rail+ 9.8 is a carbon enduro e-MTB made for chasing after distant peaks and hammering out laps. It starts out with a hard-hitting OCLV Mountain Carbon frame that partners with 160mm of front and rear travel from a Fox Performance Elite suspension package to eat up deep roots and chunky rock lines. A 12-speed wireless SRAM GX Eagle transmission keeps shifting smooth, even under serious load, while SRAM CODE Bronze 4-piston brakes provide the stopping power you need. It's finished off with a Bontrager Line dropper post and Bontrager Line Comp 30 tubeless-ready wheels for charging into anything.

Trek Rail+ 9.8 GX AXS T-Type Gen 5

Rail+ 9.9 is our top carbon enduro e-MTB made for your most epic adventures. Its robust carbon frame packs 160mm of front and rear upgraded RockShox suspension and adjustable geometry you can tune to how and where you ride. It comes equipped with a Bosch CX Line motor that delivers serious torque for ripping up climbs and a huge 800Wh RIB 2.0 removable integrated battery. It's topped off with all the bells and whistles you want – like carbon wheels and a wireless SRAM X0 transmission.

Trek Rail+ 9.9 X0 AXS T-Type Gen 5

Red Smoke

The Rail+ 9.9 is our top carbon enduro e-MTB made for your most epic adventures. Its robust carbon frame packs 160 mm of front and rear upgraded RockShox suspension and adjustable geometry you can tune to how and where you ride. It comes equipped with a Bosch CX Line motor that delivers serious torque for ripping up climbs and a huge 800 Wh RIB 2.0 removable integrated battery. It's topped off with all the bells and whistles you want – like carbon wheels and a wireless SRAM XX transmission.

	5 Gen 5	8 Gen 5	9.7 Gen 5	9.8 XT Gen 5	9.8 GX AXS T-Type Gen 5	9.9 X0 AXS T-Type Gen 5	9.9 XX AXS T-Type Gen 5
MSRP	$5,999	$6,999	$8,249	($9,889)	$10,999	$12,649	($15,124)
Spec Level
Weight	55.7 lbs	55.3 lbs	52.3 lbs	52.4 lbs	53.3 lbs	52.9 lbs	53.0 lbs
Frame	Aluminum	Aluminum	Carbon	Carbon	Carbon	Carbon	Carbon
Fork	RockShox Psylo	RockShox ZEB Select	RockShox ZEB Select	RockShox ZEB Ultimate	Fox Performance Elite Float 38	RockShox ZEB Ultimate	RockShox ZEB Ultimate
Wheels	Aluminum	Aluminum	Aluminum	Aluminum	Aluminum	Carbon	Carbon
Wheel Size	27.5″	27.5″ / 29″	27.5″	29″ / 27.5″	27.5″	27.5″	29″ / 27.5″
Brakes	Shimano Hydraulic Disc	SRAM DB8 Hydraulic Disc	SRAM DB8 Hydraulic Disc	Shimano XT Hydraulic Disc	SRAM Hydraulic Disc	SRAM Hydraulic Disc	SRAM Maven Ultimate Hydraulic Disc
Motor	Bosch 600W 85Nm mid-drive	Bosch 600W 85Nm mid-drive	Bosch 600W 85Nm mid-drive	Bosch 600W 85Nm mid-drive	Bosch 600W 85Nm mid-drive	Bosch 600W 85Nm mid-drive	Bosch 600W 85Nm mid-drive
Battery	Bosch 800Wh	Bosch 800Wh	Bosch 800Wh	Bosch 800Wh	Bosch 800Wh	Bosch 800Wh	Bosch 800Wh
Groupset	Deore	XT, SLX	XT, SLX	XT	GX Eagle Transmission	X0, X0 Eagle Transmission	XX Eagle Transmission, Eagle AXS
Drivetrain	1 × 12	1 × 12	1 × 12	1 × 12	1 × 12 Electronic	1 × 12 Electronic	1 × 12 Electronic


Wheels	27.5″	27.5″	27.5″	27.5″	27.5″	27.5″	27.5″	27.5″
Stack	598	594	631	627	649	645	672	667
Reach	435	430	455	450	495	490	520	515
Stack/Reach Ratio	1.38	1.38	1.39	1.39	1.31	1.32	1.29	1.30
Top Tube Length	562	563	591	592	639	639	670	670
Seat Tube Length	380	380	410	410	435	435	470	470
Seat Tube Angle	77.9	77.4	77.7	77.2	77.5	77.0	77.4	76.9
Head Tube Length	100	100	100	100	120	120	145	145
Head Tube Angle	65.0	64.5	65.0	64.5	65.0	64.5	64.9	64.5
BB Drop	12	18	18	24	18	24	17	24
BB Height	343	337	337	331	337	331	338	331
Front Center	755	831	784	783	832	831	867	867
Chainstay Length	446	448	446	448	446	448	446	448
Wheelbase	1,201	1,278	1,229	1,230	1,277	1,278	1,313	1,314
Rake	43		39	41	38	40	37	41
Trail	119	122	127	131	127	131	127	131
Standover Height	767	762	784	778	785	779	804	798

Rise above. Rail beyond.
