Today’s Deals2025 Trek
Rail+ 9.8 XT Gen 5
A 29″ / 27.5″ carbon frame full suspension enduro e-bike with high-end components.
Manufacturer Price
€8,499($9,889)| Weight | 52.4 lbs |
|---|---|
| Frame | Carbon |
| Suspension | Full, 160 / 160mm |
| Fork | RockShox ZEB Ultimate |
| Shock | RockShox Super Deluxe Ultimate |
| Wheels | 29″ / 27.5″ Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | XT |
| Motor | Bosch 600W 85Nm mid-drive |
| Battery | Bosch 800Wh |
| Brakes | Shimano XT Hydraulic Disc |
| Seatpost | Dropper |
5'9" – 6'3"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Nov 2025 · Ron Koch
Trek’s Rail+ Gen 5 gets more travel, a lighter Bosch Performance Line CX motor, an 800Wh battery and improved adjustability. A refined, full-power eMTB built for everyday riders.
May 2025 · Rudolf Fischer
The new 2025 Trek Rail+ 9.8 GX AXS T-Type Gen 5 with 160 mm travel and Bosch Performance Line CX Gen5 motor in the first test
Cleanly organized cockpit
Versatile platform with countless adjustment options
Cable rattling in the frame
Tires lack grip
| Frame | OCLV Mountain Carbon main frame, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9 mm seat tube, ABP, UDH Boost148, 12 mm thru axle, 160 mm travel Hanger Standard: UDH Tire Clearance: 2.6" Color: Slate |
|---|---|
| Fork | Rockshox ZEB Ultimate, DebonAir spring, Charger 3.1 RC2 damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 160 mm travel Travel: 160mm Spring Type: Air |
| Shock | RockShox Super Deluxe Ultimate RC2T, 205x65 mm Travel: 160mm |
| Headset | Integrated cartridge bearing, 1-1/8'' top, 1.5'' bottom, angle adjust cup compatible |
| Stem | Bontrager Line Pro, 35 mm, Blendr-compatible, 0-degree, 45 mm length |
| Handlebar | Bontrager Line Pro, OCLV Carbon, 35 mm, 27.5 mm rise, 780 mm width |
| Saddle | Verse Short Comp, steel rails, 145 mm width |
| Seatpost | Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length - S: Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9 mm, 410 mm length; M, L, XL: Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 34.9 mm, 450 mm length Type: Dropper |
| Pedals | VP-536 nylon platform |
| Grips | Bontrager XR Trail Elite, nylon lock-on |
| Rear Derailleur | Shimano XT M8100, long cage |
|---|---|
| Crank | E*thirteen E*spec Plus, 160 mm length |
| Shifters | Shimano XT M8100, 12-speed |
| Cassette | Shimano XT M8100, 10-51, 12-speed |
| Chain | Shimano XT M8100, 12-speed |
| Brakes | Shimano XT M8120 4-piston hydraulic disc Type: Shimano XT Hydraulic Disc |
| Rims | Front: Bontrager Line Comp 30 TLR 6-bolt Disc, Boost, Black spokes and nipples - S: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 27.5"; M, L, XL: Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle, 29", Rear: Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost148, 12 mm thru axle, 27.5" |
|---|---|
| Tires | Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5x2.50'' - S, M, L, XL: Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 27.5x2.50"; M, L, XL: Bontrager Brevard RSL SE, Tubeless Ready, triple compound, aramid bead, 60 tpi, 29x2.50" |
| Disc Rotors | Shimano RT86, 6-bolt, 203 mm |
| Motor | Bosch Performance Line CX (Europe and APAC: 25 km/h, US and ROW: 20 mph / 32 km/h) |
|---|---|
| Battery | Bosch PowerTube 800 Wh, smart system |
| Remote | Bosch System Controller BRC3100, smart system |
| Display | Bosch Mini Remote BRC3300, smart system, 22.2 mm |
| Charger | Bosch standard 4A, 230V, smart system |
| Fenders | Trek custom mudguard |
|---|
