Today’s Deals2026 Ari
SIGNAL Team XTR
A 29″ carbon frame electronic full suspension crosscountry bike with ultra high-end components.
Compare the full range
Manufacturer Price
$7,999| Frame | Carbon |
|---|---|
| Suspension | Full, Electronic, 110 / 120mm |
| Fork | RockShox SID Ultimate |
| Shock | RockShox SIDLuxe Ultimate |
| Wheels | 29″ Carbon |
| Drivetrain | 1 × 12 Electronic |
| Groupset | Dura-Ace Di2, XTR |
| Brakes | Shimano XTR Hydraulic Disc |
| Seatpost | Dropper |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full SIGNAL model range
View Comparison5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Mar 2025
The fully redesigned 2025 Ari Signal Peak rides and handles like a trail bike, but with the weight and efficiency of a pure-bred ...
Apr 2026 · Cory Benson
Prototype 32" Fox 34 SL suspension fork, alloy 32" ARI Signal Peak XC bike & i9 Solix carbon wheels. All 3 found in Maxxis 32" tire photos!
Nov 2025 · Ron Koch
The third-gen Ari Signal Peak drops 305 grams, adds new geometry and Tetra-Link Race Lite suspension, and delivers top-tier XC performance on climbs and descents.
Weight reduction of 305 grams from previous version
Efficient climbing and acceleration
Stable and confident descending, solid and predictable
Clean, simple design with two bottle cages
Attractive price for the build
Dropper-post lever position interferes with lockout lever
May 2025 · Josh Weinberg
A capable all-rounder that is equally at home on the XC race course as it is adventuring in the mountains.
Mar 2025
This full-suspension mountain bike weighs less than many hardtails and is optimized for long days on the trail.
Mar 2025 · Ari Bikes
The Signal Peak has 110mm of travel courtesy of a 'Tetra-Link' suspension layout.
Increased lateral stiffness
Less weight
Improved power transfer
Exceptional suspension characteristics
Tuned flex in the seat stays prevents pedal bob
Buttery smooth sensation off the top
Supportive mid-stroke
Stable descending with slacker head tube angle
Powerful pedaling position with steeper seat tube angle
Room for two bottles inside the front triangle
Mounts for a third under the downtube
Lightweight frame and complete bikes
Proven construction methods
No proprietary parts
Tube-in-tube cable routing
Threaded bottom bracket
| Frame | Ari Signal Peak 3.0 Clean Cast™ Carbon, 110mm of Tetra-Link™ Race Lite suspension travel, internal tube-in-tube cable routing, 12x148mm Full-Mount UDH dropout, threaded BB, 2 bottle cage mounts (all frame sizes) BB Standard: BSA, Threaded Hanger Standard: UDH Tire Clearance: 2.4" Colors: Raw Carbon; Fog Grey Navy; Raw Carbon / Purple |
|---|---|
| Fork | Rockshox SID Ultimate, 3 Position Remote, Charger Race Day 2, DebonAir+ 120mm travel, 15x110 Axle, tapered steerer *not shown in photo, Flight Attendant Available at checkout Travel: 120mm Spring Type: Air |
| Shock | Rockshox SIDLuxe Ultimate, 3 Position Remote, 190x45mm *not shown in photo, Custom Tuned, Flight Attendant Available at checkout Travel: 110mm |
| Bottom Bracket | Shimano XTR BB93 English |
| Headset | Cane Creek 40 Series ZS Tapered ZS44 ZS56/40 |
| Stem | Raceface Turbine, 35mm |
| Handlebar | Raceface Era 35 Handlebar - 760mm Wide, 35mm Clamp, 10mm Rise, bar-customized sizing through Ari Custom Setup |
| Saddle | WTB Silverado 265 Medium Titanium Fusion Form |
| Seatpost | Fox Transfer Performance Elite Dropper- customized sizing through Ari Custom Setup Type: Dropper |
| Pedals | Available Separately |
| Rear Derailleur | Shimano XTR M9250 SGS, 12-Speed |
|---|---|
| Front Derailleur | N/A |
| Crank | Shimano XTR M9220 -customized sizing through Ari Custom Setup |
| Shifters | Shimano XTR M9250 |
| Cassette | Shimano XTR M9200, 9-45t, 12-Speed |
| Chain | Shimano XTR M9100, 12-Speed |
| Brakes | Shimano XTR M9220 4-Piston, 180/180mm F/R Rotors Type: Shimano XTR Hydraulic Disc |
| Rims | Industry Nine 1/1 Whisp Carbon 29, 28h Tubeless Ready |
|---|---|
| Spokes | Sapim Race J-Bend |
| Front Hub | F: I9 1/1, Disc, 15x110 thru axle, R: I9 1/1 hub, Disc, 12x148 thru axle, MicroSpline |
| Rear Hub | F: I9 1/1, Disc, 15x110 thru axle, R: I9 1/1 hub, Disc, 12x148 thru axle, MicroSpline |
| Tires | Maxxis Rekon Race 29x2.4WT, Maxxspeed, EXO, Tubeless Ready |
