Released November 2
Photo Credit: Transition
Builds
1
Price
$2,599
Wheels
29″ Aluminum
Suspension
Hardtail, 150mm
Frame Material
Steel
IT WILL STEEL YOUR HEART
The classic TransAm returns! After a seven-year hiatus, the reliable trail-shredding hardtail is back in the lineup for a limited time.
Now with modern geometry, dual 29-inch wheels, a capable build spec or frameset option, and two classic color schemes, this will be one to hang on to and pass down for many generations. The updated geo encourages hard-charging but rewards thoughtful line choice. It orchestrates a fast-paced ballet through the landscape of your choosing. The new TransAM is ready for the rider looking to get back to their roots.
The highs and lows of this model family
| MSRP | $2,599 |
|---|---|
| Spec Level | |
| Weight | 33.0 lbs |
| Fork | Marzocchi Bomber Z2 |
| Groupset | NX Eagle, Truvativ Descendant |
| Drivetrain | 1 × 12 |
| Where to Buy | $2,599 At Transition |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
| Wheels | 29″ | 29″ | 29″ | 29″ |
|---|---|---|---|---|
| Stack | 645 | 645 | 650 | 659 |
| Reach | 434 | 464 | 489 | 514 |
| Stack/Reach Ratio | 1.49 | 1.39 | 1.33 | 1.28 |
| Top Tube Length | 588 | 618 | 644 | 671 |
| Seat Tube Length | 370 | 400 | 430 | 460 |
| Seat Tube Angle | 76.5 | 76.5 | 76.5 | 76.5 |
| Head Tube Length | 105 | 105 | 110 | 120 |
| Head Tube Angle | 64.0 | 64.0 | 64.0 | 64.0 |
| BB Drop | 50 | 50 | 50 | 50 |
| BB Height | 320 | 320 | 320 | 320 |
| Front Center | 767 | 799 | 825 | 855 |
| Chainstay Length | 429 | 429 | 429 | 429 |
| Wheelbase | 1,191 | 1,223 | 1,250 | 1,280 |
| Rake | 44 | 44 | 44 | 44 |
| Trail | 136 | 134 | 135 | 134 |
| Standover Height | 666 | 671 | 674 | 681 |
🐐 Measurements listed in millimeters and degrees
