 | Recommended |
|---|
MSRP | $3,249 | |
|---|---|---|
Where to Buy | — $1 At | |
Category | Trail, E-Bike | |
| Aluminum | ||
Fork | Suntour RAIDON | |
Wheels | Aluminum | |
| 27.5″ | ||
Brakes | Hydraulic Disc | |
| Shimano 250W 60Nm mid-drive | ||
| Shimano 500Wh | ||
Groupset | Deore, Shimano | |
Drivetrain | 1 × 10 | |
Suspension | Hardtail | |
Front Travel | 120mm | |
Brand Site | ||
Summary | The Haro Subvert i/O 5 is a 27.5″ aluminum frame hardtail trail e-bike with upper mid-range components. | |
Based on frame geometry and build specs.
Frame | Subvert I/O X6 Aluminum frame for Shimano STePS E7000, Tapered head tube | |
|---|---|---|
Fork | SR Suntour Raidon 34mm, Boost LOR-DS 27.5" Plus, 120mm travel, 15mm Thru-Axle, w/ Hydraulic Lockout | |
Bottom Bracket | N/A | |
Headset | FPD Dozer 1-1/8"-1.5", w/ Bottom AC Bearing, 8mm Cone | |
Stem | New Pivit 3D Forged alloy 60mm | |
Handlebar | New Pivit Alloy riser bar, 760mm wide; 20mm rise | |
Saddle | WTB Volt Sport Wide 150mm | |
Seatpost | Pivit Light, 2 Bolts, Forged alloy, 31.6x 350 / 400mm | |
Pedals | N/A |
Rear Derailleur | Shimano Deore, RD-M6000, 10-spd, Shadow Plus | |
|---|---|---|
Front Derailleur | N/A | |
Crank | Shimano E7000 forged, 34T Chainring | |
Shifters | Shimano Deore RapidFire+ 10-spd | |
Cassette | Shimano Deore HG-500, 10-spd, 11-42T | |
Chain | KMC e10S Sport | |
Brakes | New Tektro HD-M735 hydraulic, 4-Piston front, 2-Piston rear, 203/180mm rotors | |
Brake Levers | New Tektro HD-M735 |
Rims | Weinmann U-40 TL, Tubeless Ready, 27.5"x40mm, Double Wall | |
|---|---|---|
Front Hub | Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle | |
Rear Hub | Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle | |
Tires | Kenda HAVOC 27.5x2.8", 120tpi, Aramid beads, Tubeless Compatible |
Motor | Shimano STePS E7000, 250 W, 60Nm Torque | |
|---|---|---|
Battery | Shimano STePS E8010, 500Wh |
