2019 Haro
Subvert i/O 5
A 27.5″ aluminum frame hardtail trail e-bike with upper mid-range components.
Compare the full range
Manufacturer Price
$3,249| Frame | Aluminum |
|---|---|
| Suspension | Hardtail, 120mm |
| Fork | Suntour RAIDON |
| Wheels | 27.5″ Aluminum |
| Drivetrain | 1 × 10 |
| Groupset | Deore, Shimano |
| Motor | Shimano 250W 60Nm mid-drive |
| Battery | Shimano 500Wh |
| Brakes | Hydraulic Disc |
For This Bike
5'1" – 5'6"
5'4" – 5'9"
5'7" – 6'0"
5'10" – 6'3"
6'0" – 6'5"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | Subvert I/O X6 Aluminum frame for Shimano STePS E7000, Tapered head tube |
|---|---|
| Fork | SR Suntour Raidon 34mm, Boost LOR-DS 27.5" Plus, 120mm travel, 15mm Thru-Axle, w/ Hydraulic Lockout Travel: 120mm Spring Type: Air |
| Bottom Bracket | N/A |
| Headset | FPD Dozer 1-1/8"-1.5", w/ Bottom AC Bearing, 8mm Cone |
| Stem | New Pivit 3D Forged alloy 60mm |
| Handlebar | New Pivit Alloy riser bar, 760mm wide; 20mm rise |
| Saddle | WTB Volt Sport Wide 150mm |
| Seatpost | Pivit Light, 2 Bolts, Forged alloy, 31.6x 350 / 400mm Type: Rigid |
| Pedals | N/A |
| Rear Derailleur | Shimano Deore, RD-M6000, 10-spd, Shadow Plus |
|---|---|
| Front Derailleur | N/A |
| Crank | Shimano E7000 forged, 34T Chainring |
| Shifters | Shimano Deore RapidFire+ 10-spd |
| Cassette | Shimano Deore HG-500, 10-spd, 11-42T |
| Chain | KMC e10S Sport |
| Brakes | New Tektro HD-M735 hydraulic, 4-Piston front, 2-Piston rear, 203/180mm rotors Type: Hydraulic Disc |
| Brake Levers | New Tektro HD-M735 |
| Rims | Weinmann U-40 TL, Tubeless Ready, 27.5"x40mm, Double Wall |
|---|---|
| Front Hub | Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle |
| Rear Hub | Pivit Alloy disc Boost, 32h cassette, Sealed Bearings, w/ Front & Rear Thru-Axle |
| Tires | Kenda HAVOC 27.5x2.8", 120tpi, Aramid beads, Tubeless Compatible |
| Motor | Shimano STePS E7000, 250 W, 60Nm Torque |
|---|---|
| Battery | Shimano STePS E8010, 500Wh |
