Today’s Deals2022 ZEN
Samurai
A 650b aluminum frame women’s commuter e-bike with high-end components and magura mt5 estop hydraulic disc brakes.
Manufacturer Price
$4,600| Weight | 57.0 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail, 120mm |
| Fork | Fox AWL |
| Wheels | 650b Aluminum |
| Drivetrain | Belt Drive, Internally Geared Hub |
| Groupset | e*thirteen |
| Motor | Bosch 350W 85Nm mid-drive |
| Battery | Bosch 500Wh |
| Brakes | Magura MT5 eSTOP Hydraulic Disc |
3'11" +
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Jun 2023 · Forrest Woolman
Top of the Line Technology and Energy Efficiency with this Awesome Bosch-Powered Adventure e-Bike With summertime's arrival, many of us are thinking about our upcoming adventures. Whether they be short or long, in the city or out in the boonies, the Zen Samurai adventure/touring e-bike can give you a thrilling time. Designed by Guinness World
Comfort and perfomance galore. It’s a tech-loaded bike with all the features really enhancing the ride.
Balanced power distribution from the Bosch mid-drive motor.
Easy gear selection with the Enviolo Continuously Variable Transmission (CVT) 380 internal gear hub.
Cleaner, quieter and longer lasting Gates Carbon Drive belt.
Efficient energy use, and up to 50-mile range on one Bosch 13.4Ah battery.
Battery charges in 2-3 hours with the 4-amp fast charger.
Both the Bosch motor and Bosch battery are UL certified, giving you increased safety and reliability.
Lots of customization options, including battery, frame size, gear hubs, forks, lights, display units, seatpost suspension, brakes, paint color and tires.
It’s great value in terms of what you get for what you pay on the base model, but it is a pretty high starting price point that can add over a thousand more for enhanced features.
Honestly, we couldn’t find major flaws with this bike, leaving us to fret about minor things, like wanting a 2nd battery charger – so we could ride sooner!
May 2022
Price: $4600.00 | Model Year: 2022 | A premium commuter, touring capable, electric bike with Bosch Gen 4 Speed motor capable of 28mph. Offers clean quiet Gates Carbon belt drive, powerful Magura hydraulic disc brakes, and Enviolo continuously variable transmission.
A premium commuter, touring capable, electric bike with Bosch Gen 4 Speed motor capable of 28mph. Offers clean quiet Gates Carbon belt drive, powerful Magura hydraulic disc brakes, and Enviolo continuously variable transmission.
Comes stock with a Bosch PowerTube 500 battery pack and 4 amp fast charger. Optional PowerPack 500 doubles range while keeping weight low and center. Four frame sizes, adjustable angle stem, and Ergon touch points ensure comfort.
Custom suspension seat post pairs with Manitou air suspension to offer comfort at speed and over long distances. Included SKS fenders, sturdy rear rack, and optimally positioned light offer safety and utility.
Weighs a bit more because it comes feature-complete. Pricing starts at $4.6k but rises sharply with optional suspension, brake, and drivetrain upgrades. Battery charge port and downtube cover could be refined.
| Frame | 6061 Aluminium Alloy, Custom Hydroformed |
|---|---|
| Fork | Manitou Machete Air Suspension, 120mm Travel, Compression, Rebound Adjust, 34mm Black Anodized Stanchions, Boost 110mm Hub Spacing, 15mm Thru-Axle with Quick Release, Optional Fox AWL Ebike Specific Air Suspension Fork 34 120mm Travel Travel: 120mm Spring Type: Air |
| Headset | Cane Creek, Internal, Sealed Bearing, Tapered 1-1/8" to 1-1/2" |
| Stem | Custom Designed Satori, Adjustable Angle, Aluminum Alloy, 65mm or 90mm or 110mm Length, 0° to 60°, Two 10mm Spacers, 31.8mm Clamp Diameter |
| Handlebar | ZEN Custom, Aluminum Alloy, Low-Rise, 680mm Length, 20mm Rise, 15° Backsweep, 31.8mm Bore, Optional Female Specific Handlebar |
| Saddle | Ergon SF3 Gel, Optional Female Specific Ergon Saddle |
| Seatpost | Custom Designed Suspension Seatpost, Optional Kinekt Suspension Seatpost Type: Suspension |
| Pedals | OneUp Composite Platform with Adjustable Pins, Sealed Rebuildable Ceramic Bearings |
| Grips | Ergon GP1, Ergonomic, Locking |
| Crank | E*thirteen Alloy 165mm or 170mm Crank Arms, 55 Tooth CDX or CDX EXP Belt Chainring |
|---|---|
| Shifters | Enviolo Half-Grip Twist Shift on Right (Rider Infographic, Powered by NuVinci), Optional Kindernay 7-Speed Triggers, Optional Rohloff E14 Electronic Buttons |
| Cassette | 1 Speed 1x∞ Enviolo 380 Heavy Duty Edition Mechanical Continuously Variable Transmission, 22 Tooth Belt Sprocket |
| Brakes | Magura CT4 Hydraulic Disc with 180mm Rotors, 6 Bolt Pattern, Dual-Piston Calipers, Three-Finger Levers with Adjustable Reach, Optional Magura MT5E Quad Piston Brakes Type: Magura MT5 eSTOP Hydraulic Disc |
| Rims | Double Wall, Aluminum Alloy, 25mm or 35mm Outer Width, 36 Hole |
|---|---|
| Spokes | Sapim, Stainless Steel, 14 Gauge, Double Butted, Black with Nipples |
| Tires | Schwalbe Super Moto-X, 27.5" x 2.4" (62-584) |
| Motor | Weight: 6.3 lbs (2.85 kg), Brand: Bosch Gen 4 Performance Line Speed or CX, Type: Mid-Mounted Geared Motor, Nominal Output: 350 watts, Torque: 85 Newton meters |
|---|---|
| Battery | Weight: 6.3 lbs (2.85 kg), Brand: Bosch PowerTube 500 3500mAh 18650 Cells, Optional Bosch PowerPack 500, Voltage: 36 volts, Amp Hours: 13.4 ah (Optional 13.4Ah Bosch PowerPack 500), Watt Hours: 500 wh (Optional 1,000Wh total with Bosch PowerPack 500), Chemistry: Lithium-ion |
| Display | Bosch Intuvia, Removable,2.7" Backlit Grayscale Display, Buttons: Reset, Power, i, Lights, (Hold Reset and i for Settings Menu) |
