A 27.5″ hardtail crosscountry e-bike with mid-range components.
Compare the full range
Manufacturer Price
$2,599| Weight | 7.7 lbs (frame) |
|---|---|
| Suspension | Hardtail, 110mm |
| Fork | Suntour XCM |
| Wheels | 27.5″ Aluminum |
| Drivetrain | 1 × 9 |
| Groupset | X5 |
| Motor | Bafang hub-drive |
| Battery | 672Wh |
| Brakes | Tektro Hydraulic Disc |
Jan 2024
Price: $2599.00 | Model Year: 2023 | An extra-small hardtail electric mountain bike with 26
An extra-small hardtail electric mountain bike with 26" wheels. Features Boost hub spacing, plus sized 2.8" wide tires, 15mm thru-axle, 9-speed SRAM X5 drivetrain 11-36T, adjustable top speed, responsive torque sensing pedal assist, and trigger throttle operation.
Adjustable spring suspension fork with lockout and preload adjust. Upright geometry with short stem, excellent headlight placement on a metal bracket at the stem. The bike is pre-wired for a rear light that works with the optional rear rack. Optional 20 amp hour battery can greatly extend range.
Powerful 180mm hydraulic disc brakes with motor inhibitors on both levers. Large color display with integrated USB charging port is easy to read. Second USB charging port on side of standard and large battery packs! Nice adjustable kickstand, but it could cause heal strikes if you have long feet or large shoes. Flick bell, locking Velo grips, sturdy Wellgo pedals.
Narrow-wide chainring helps to prevent drops, but there's no slap guard to protect the chain stay from chips. The bike is fairly heavy for a hardtail, due to the spring suspension fork vs. air, larger tires, reinforced frame, and high capacity battery packs. The tires aren't puncture resistant or reflective. No bottle cage mounts like the full sized Shred models. Charge port is in the path of the left crank arm for the standard battery pack.
| Fork | SR Suntour XCM 32 Spring Suspension, 110 mm Travel, Compression Adjust with Lockout, Preload Adjust, 32 mm Steel Stanchions, 110 mm Hub Spacing, 15 mm Thru Axle with 6 mm Hex Bolts Travel: 110mm Spring Type: Coil |
|---|---|
| Headset | SAMOX Tapered with Sealed Bearings, Tapered 1-1/8" to 1-1/2" |
| Stem | UNO, Aluminum Alloy, 40° Angle, 90 mm Length, 20 mm Tapered Base Spacer, One 10 mm Spacer, One 5 mm Spacer |
| Handlebar | PROMAX Aluminum Alloy, 30mm Rise With 9° Backsweep, 720mm Length |
| Saddle | Selle Royal Essenza Plus Gel, Adjustable up to 9 Degrees |
| Seatpost | Alloy, Forged Head, Dual Bolt Type: Rigid |
| Pedals | Wellgo Aluminum Alloy Platform with Fixed Pins |
| Grips | Velo, Flat Rubber, Locking, Black |
| Rear Derailleur | SRAM X5 9-Speed 1-Piece Forged CNC with 2 Sealed Bearings |
|---|---|
| Crank | Samox, Forged Alloy, Sealed Cartridge Bearings, Hollow Spindle, 170 mm Length, 38 Tooth Narrow Wide Alloy Chainring |
| Shifters | SRAM X5 Triggers on Right |
| Cassette | SRAM 12-34 Tooth |
| Brakes | Tektro E500 Hydraulic Disc with 180mm Rotors that are 2.35mm Thick, Dual-Piston Calipers with Resin Composite Pads, Three-Finger Tektro Levers with Adjustable Reach and Motor Inhibitors Type: Tektro Hydraulic Disc |
| Rims | 27.5 |
|---|
| Motor | Type: Hub, Output: 500, Details: Bafang RM G360.500.DC, Weight: 9 lbs (4.08 kg) |
|---|---|
| Battery | Watt Hours: 672 Wh, Details: Samsung 18650 or 21700 (3,500mAh or 5,000mAh Cells), Reention Dorado Casing or Custom Casing 48 Volt, Lithium-ion, 14 Amp Hrs, (Optional 20 ah), Battery Weight: 14AH battery 3.45kg (7.5lbs) 20AH battery 4.65kg (10lbs), Weight: 7.7 lbs (3.49 kg) (672wh Battery, 10lb for 960wh Battery) |
| Display | Surface 604 Branded, Fixed, Adjustable Angle, 3.5" Color, Backlit LCD, USB Type A Charging Port on Base |
| Lights | BÜCHEL SHINY 120 LED Headlight Mounted to Stem, Pre-Wired To Connect to Rear Stop Light |
|---|
