5'2" – 5'7"
5'6" – 5'11"
5'9" – 6'2"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Frame | Specialized Diverge E5 Premium Aluminum, Future Shock suspension, 1x specific EVO geometry, threaded BB, internal routing, 12x142mm thru-axle, flat-mount disc BB Standard: BSA, 68mm, Threaded Tire Clearance: 47c Color: Satin Pine / Forest/chrome/clean |
---|---|
Fork | Future Shock 1.5 w/Smooth Boot, FACT carbon, 12x100 mm thru-axle, flat-mount Travel: 20mm |
Bottom Bracket | SRAM DUB BSA 68 Wide |
Stem | Future Stem, Comp |
Handlebar | Specialized Alloy Minirise, 10mm rise, 750mm, 31.8mm clamp |
Saddle | Body Geometry Power Sport, steel rails |
Seatpost | TranzX Dropper, 27.2mm, 90mm travel Type: Dropper |
Grips | Specialized Trail Grips |
Rear Derailleur | SRAM GX Eagle, 12-speed |
---|---|
Crank | SRAM Rival 1 Wide, 38T |
Shifters | SRAM GX, trigger, 12-speed |
Cassette | SRAM NX Eagle, 12-speed, 11-50t |
Chain | SRAM GX Eagle, 12-speed |
Brakes | Front: SRAM Level TLM, hydraulic disc, 160mm CenterLine rotor, Rear: SRAM Level TLM, hydraulic disc, 160mm CenterLine rotor Type: Hydraulic Disc |
Rims | Front: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples, Rear: DT Swiss G540 rim, 24mm internal width, tubeless ready, 24h, Specialized full sealed bearing thru axle hub, centerlock disc, DT Swiss Champion 14G stainless steel spokes, DT Swiss brass nipples |
---|---|
Tires | Front: Rhombus Pro, 2Bliss Ready, 700x42mm, Rear: Rhombus Pro, 2Bliss Ready, 700x42mm |
Last updated April 15
