Midnight Grey

Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm

SR Suntour NRX32-E Air LO R, Tapered, 15x100 bolt Axle, Remote Lock Out, Alloy Steerer, 75mm Travel

Alloy S-L=29", 6061 Alloy custom butted tubing; Top extraction battery

Alloy Handle Bar, Rise 12mm, Backsweep 15°, 680mm wide

Acros, 1.5"- 1.5"; semi integ. OD 50/61mm, ID 44/55mm

Lezyne Fusion E550SM front light; Rear Supernova TL3Z

Bosch Performance Line SX (BDU314Y); EU: 25kmh

Front: Schwalbe G-One Overland 365 Performance, 700x45C, Rear: Schwalbe G-One Overland 365 Performance, 700x45C

The Passage 10 Wave Bike is our e-URBAN machine that’s easy to ride, thanks to its low standover height, making it a cinch for everyone in the family to get on and enjoy riding in the city. At first glance, you may not even register Passage 10 as an E-Bike, with its trim lines and non-intimidating stance. That’s thanks to Bosch’s SX motor (which weighs just 2kg) and slim 400Wh battery. It’s a powerful combo that keeps the bike light, agile, and balanced while delivering power whenever you need it and the range to handle a long commute easily. In addition to being easy to mount, Passage 10 is nicer to ride than larger E-Bikes. The Bosch SX motor features a narrower Q-factor that lets you have a natural pedaling style and handling you may be used to feeling on lightweight bikes. Out front is a 75mm suspension fork that cushions your ride from rougher pavement as you zip around town. And if taking the scenic route or packing extra for the commute in, the rear rack sets you up to stow the day’s essentials. We equipped this Passage 10 with Shimano’s 8-speed drivetrain for plenty of gearing to enjoy your city streets and 45mm tires to add stability and comfort to navigate any surprises on the route. There’s also a kickstand for easy parking at your destination. Please note that bike specifications are subject to change without prior notice. condition of usage 2, Example Trekking bike, travel bike, Please check the detail for more information

Scott Passage 10 Wave

130kg; The overall weight includes the bike, the rider, the equipment, and possible additional luggage.

A 29″ aluminum frame hardtail crosscountry e-bike with high-end components.

Weight	49.6 lbs
Frame	Aluminum
Suspension	Hardtail, 75mm
Fork	Suntour NRX
Wheels	29″ Aluminum
Drivetrain	Belt Drive, Internally Geared Hub
Groupset	Alfine
Motor	Bosch 600W 55Nm mid-drive
Battery	400Wh
Brakes	Shimano Hydraulic Disc

Frame	Alloy S-L=29", 6061 Alloy custom butted tubing; Top extraction battery Color: Midnight Grey
Fork	SR Suntour NRX32-E Air LO R, Tapered, 15x100 bolt Axle, Remote Lock Out, Alloy Steerer, 75mm Travel Travel: 75mm Spring Type: Air
Headset	Acros, 1.5"- 1.5"; semi integ. OD 50/61mm, ID 44/55mm
Stem	Adjustable stem 90mm 10°-60
Handlebar	Alloy Handle Bar, Rise 12mm, Backsweep 15°, 680mm wide
Saddle	Syncros Capilano
Seatpost	Syncros M3.0, 31.6 Type: Rigid
Pedals	Marwi SP-827

Crank	FSA CK-220 170mm
Shifters	Shimano Alfine SL-S503 Rapid Fire Plus
Cassette	Gates CDC 26T
Chain	Gates CDC 125T
Brakes	Shimano BR-MT200 Disc Type: Shimano Hydraulic Disc

Rims	Syncros X15 Disc
Spokes	Black Spokes
Front Hub	Shimano HBTC50015B CL, 15x100mm
Rear Hub	Shimano Nexus 8 Speed
Tires	Front: Schwalbe G-One Overland 365 Performance, 700x45C, Rear: Schwalbe G-One Overland 365 Performance, 700x45C
Disc Rotors	Front: SM-RT30 CL 180mm, Rear: SM-RT30 CL 160mm

Motor	Bosch Performance Line SX (BDU314Y); EU: 25kmh
Battery	Compact Tube 400Wh
Display	Bosch Purion 200
Charger	2A Charger

Lights	Lezyne Fusion E550SM front light; Rear Supernova TL3Z
Racks	Racktime Micro Rack SnapIt 2.0 8KG

2026 ScottPassage 10 Wave

2026 Scott
Passage 10 Wave
