2026 Radon
RELATE 9.0 800

A 700c aluminum frame commuter e-bike with upper mid-range components and shimano xt hydraulic disc brakes.
Compare the full range

Manufacturer Price

€3,999($4,653)

Where to Buy

Similar Bikes

Top Comparison

Insights

Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

35 mph

RELATE 9.0 800

31 mph

Similar Bikes

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full RELATE model range

Price History

Specs

Build

Frame	RELATE 800; Material: Aluminium, Powertube battery 800Wh horizontal, Hanger: UDH Hanger Standard: UDH Color: Deepblack / Foxylady
Fork	Fox 34 AWL, Sport, E-Optimized, Boost Travel: 100mm Spring Type: Air
Headset	Acros ICR, ZS56/ZS56
Stem	Humpert Swell-R Eco adjust, Ø31.8mm; 50cm: 100mm, 54cm: 100mm, 58cm: 100mm, 62cm: 120mm
Handlebar	RADON Comfort Trail Bar, Ø31.8 x 680mm
Saddle	ACID Sequence Pro Plus
Seatpost	RADON suspension seatpost, 30.9 x 350mm Type: Suspension
Pedals	ACID FLAT C3-ZP
Grips	ACID Hybrid Tour

Groupset

Rear Derailleur	Shimano XT Di2 RD-M8260-SGS, 12-speed
Crank	ACID E-Crank, 40T, 175mm
Shifters	Shimano DEORE Di2 SW-M6250-IR, I-Spec EV
Cassette	Shimano DEORE CS-M6100, 10-51
Chain	Shimano DEORE CN-M6100
Chain Guide	Reverse Components Flip-Guide, direct mount
Brakes	Shimano XT BR-M8120 Type: Shimano XT Hydraulic Disc

Wheels

Rims	ACID EX25
Spokes	Pillar C14 ED black
Front Hub	ACID BASIC MTB, 110mm
Rear Hub	ACID BASIC MTB, 148mm
Tires	Schwalbe Marathon Efficiency, Evo, Reflex, 28" x 55mm

Electric Components

Motor	Bosch Performance Line CX Gen5 Smart System
Battery	Bosch Powertube 800Wh; Bosch Power More 250: compatible ✔
Display	Bosch LED Remote / Bosch Kiox 500

Accessories

Lights	Front: Busch & Müller Lumotec IQ-XS Light E-Bike, Rear: ACID PRO-E SIC 2.0 Brake
Racks	ACID IC 3.0 RILink
Bell	Knog Oi
