2019 Orbea
GAIN M20i USA
A carbon frame endurance e-bike with high-end components and hydraulic disc brakes.
Compare the full range
| MSRP | $5,799 |
|---|---|
| Reported Weight | 26.7 lbs |
| Frame | Carbon |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 700c Aluminum |
| Drivetrain | 2 × 11 Electronic |
| Groupset | Ultegra Di2, Shimano |
| Motor | hub-drive |
| Brakes | Hydraulic Disc |
For This Bike
4'11" – 5'4"
5'2" – 5'8"
5'6" – 6'0"
5'10" – 6'4"
6'2" – 6'7"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Nov 2019 · Warren Rossiter
Hugely fun, even with the motor switched off. The Gain is a real pleasure to ride
Subtle assistance, can be bespoke
Wheel upgrade is a must to get the best from the bike
Aug 2019 · Benjamin Topf
The Orbea Gain M10 stands out from the crowd with its upbeat colour scheme. Read on to find out how the bike fared in our group test.
High level of integration
Sporty character
Lots of tire clearance
Not the most comfortable
Front more agile than the rear
Apr 2019 · Charles Graham-Dixon
It may seem unorthodox to most dedicated roadies, but the Gain integrates electric assistance into a thoroughly slick road bike package
Great handling
Intuitive controls and a smooth motor assistance
The weight is a slight penalty when riding above 25kmh limit
Jun 2018
If you want an e-bike that doesn't look like an e-bike, the Gain range from Basque brand Orbea might well hit the spot. Orbea describes it quite accurately as being designed to "enhance your ride, not dominate it". What they're getting at is the fact that the motor is significantly less powerful than the Shimano or Bosch mid-mounted motors that most e-bikes have at this price point, but at 14kg it's also much lighter than most e-bikes. This is not a bike that can get you up a hill looking serene like Jimmy Carr.
| Frame | Orbea Gain Carbon, Monocoque carbon structure, Flat Mount Disc Brakes, 135x9 QR, max 700x40C, Inner Cable routing, Ebikemotion X35 specific, integrated battery, integrated sensor, Iwock One compatible Tire Clearance: 40c |
|---|---|
| Fork | Gain Carbon Flat mount |
| Headset | FSA 1-1/8 - 1-1/2" Integrated Carbon Cup ACB Bearings |
| Stem | FSA Energy |
| Handlebar | FSA Energy Compact |
| Saddle | Prologo Kappa Space STN size 147mm |
| Seatpost | FSA K-Force SB25 31.6x350mm Di2 compatible Type: Rigid |
| Pedals | N/A |
| Rear Derailleur | Shimano Ultegra Di2 R8050 GS |
|---|---|
| Front Derailleur | Shimano Ultegra Di2 R8050 |
| Crank | Shimano Ultegra R8000 34x50t |
| Shifters | Shimano ST-8070 |
| Cassette | Shimano Ultegra R8000 11-32t 11-Speed |
| Chain | KMC e11 Turbo Silver |
| Brakes | Shimano R8070 Hydraulic Disc Type: Hydraulic Disc |
| Rims | Mavic Aksium Elite Disc UST |
|---|---|
| Front Hub | Orbea Road 12x100mm, thread M12xP1.5 |
| Tires | Mavic Yksion Pro 700x28 UST |
| Motor | Ebikemotion X35 |
|---|---|
| Battery | Ebikemotion 36V/6.9A |
| Charger | Ebikemotion X35 |
