2020 Norco

Charger VLT

A 29″ aluminum frame hardtail trail e-bike with modest components.

Manufacturer Price

$3,399
FrameAluminum
SuspensionHardtail, 120mm
ForkSuntour XCM
Wheels29″ Aluminum
Drivetrain1 × 9
GroupsetAltus
MotorShimano 250W 60Nm mid-drive
BatteryShimano 504Wh
BrakesHydraulic Disc
SeatpostDropper
View on norco.comLearn about Norco
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes

For This Bike

Accessories
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
Charger VLT
Other Trail bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

27 mph

Charger VLT

26 mph

Similar Bikes

Highest gear

(descending)

Sizing
SM

5'2" – 5'8"

MD

5'6" – 5'11"

LG

5'10" – 6'3"

XL

6'1" – 6'7"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry
99 Spokes on YouTube99 Spokes on YouTube
Specs
Build
Frame

6061 Aluminum Frame, Fender Mounts, Rack Mounts, Bottle Mount

Fork

SR Suntour XCM32 DS, 120mm Travel, E-Bike

Travel: 120mm

Spring Type: Coil

Headset

FSA No.57E Sealed Bearing

Stem

Alloy, 60mm Length, 31.8mm Clamp

Handlebar

Butted 6061 Alloy, 740mm, 20mm Rise

Saddle

Norco XC

Seatpost

TranzX YSP18 Dropper, 31.6mm, 130mm

Type: Dropper

Pedals

VP Nylon Flat

Grips

VP Lock-On

Groupset
Rear Derailleur

Shimano Altus M-2000

Crank

Prowheel E8000, 170mm, 34T

Shifters

Shimano Altus SL-M2010

Cassette

Shimano Acera CS-HG2009, 11/36T, 9 Speed

Chain

KMC e9S E-Bike

Brakes

Front: Tektro HD-M285 Hydraulic, E-Bike, Rear: Tektro HD-M285 Hydraulic, E-Bike

Type: Hydraulic Disc

Brake Levers

Tektro HD-M285

Wheels
Rims

Alex MD25 TRS 29", 32H

Front Hub

Alloy 15x110mm Boost, 6 Bolt

Rear Hub

Alloy 12x148mm Boost, HG, 6 Bolt

Tires

Front: WTB Ranger Comp 2.25", Rear: WTB Ranger Comp 2.25"

Disc Rotors

Tektro 180mm

Electric Components
Motor

Shimano STEPS E7000

Battery

Shimano STEPS E8035 Downtube

Recycling Program: ♻️ Call2Recycle

Display

Shimano STEPS E7000
