2010 Norco
'10 Jasmine
A 20″ steel frame mountain youth bike with mid-range components and rim brakes.
| Frame | Steel |
|---|---|
| Suspension | Hardtail, 30mm |
| Wheels | 20″ Aluminum |
| Drivetrain | 2 × 6 |
| Groupset | Tourney, SRAM |
| Brakes | Rim |
For This Bike
| Frame | Hi-Ten Steel |
|---|---|
| Fork | Bravo single crown suspension fork 30mm travel Travel: 30mm |
| Bottom Bracket | Chin Haur with boron axle |
| Headset | Chin Haur Steel 1" sealed |
| Stem | Steel 80mm |
| Handlebar | Steel 540mm |
| Saddle | Custom |
| Seatpost | Alloy 25.4 x 250mm Type: Rigid |
| Pedals | Wellgo plastic 9/16 with reflectors |
| Grips | Velo Krayton rubber |
| Rear Derailleur | Shimano TY-18 |
|---|---|
| Front Derailleur | Shimano TZ-30 28.6 |
| Crank | Prowheel 140mm with 42/34 rings |
| Shifters | SRAM MRX |
| Cassette | Shimano TZ-20 6 speed 14-28 |
| Chain | KMC |
| Brakes | Front: Tektro alloy v-brake, Rear: Tektro alloy v-brake Type: Rim |
| Brake Levers | Tektro alloy adjustable |
| Rims | Alloy 36 hole |
|---|---|
| Front Hub | KT Steel nutted 36 hole |
| Rear Hub | KT Steel nutted 36 hole |
| Tires | 20" x 1.75 |
Last updated July 10
Not listed for 2,483 days
