2026 KTM

MACINA GRAN 810 ABS 29

A 29″ aluminum frame hardtail crosscountry e-bike with high-end components.
Compare the full range

Manufacturer Price

€4,999($5,729)
Price History
FrameAluminum
SuspensionHardtail, 80mm
ForkSuntour MOBIE
Wheels29″
Drivetrain1 × 11
GroupsetXT
MotorBosch 600W 100Nm mid-drive
BatteryBosch 800Wh
BrakesShimano XT Hydraulic Disc
SeatpostDropper
View on ktm-bikes.atLearn about KTM
Add to Comparison
Shop with an Expert at Upway
Where to Buy

($5,729)

KTM logoKTM

MACINA GRAN 810 ABS 29

Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
MACINA GRAN 810 ABS 29
Other Crosscountry bikes
Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full MACINA GRAN model range

View Comparison
Sizing
XS

4'11" – 5'5"

SM

5'2" – 5'7"

MD

5'4" – 5'10"

LG

5'7" – 6'1"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Price History
Geometry
Specs
Build
Frame

Macina Trekking Onroad Alloy 6061|PT800 Bosch BDU38/T5940

BB Standard: Bosch, Press Fit

Fork

Suntour Mobie34 Air 29" 2CR 80mm 15QLC

Travel: 80mm

Spring Type: Air

Bottom Bracket

Bosch, press-fit

Headset

Acros AICR internal 1.5"-1.5"

Stem

KTM adjust. 0-60° ICR

Handlebar

Ergotec Lady Town 630mm

Saddle

Selle Royal Lookin 3D

Seatpost

KTM Line dropper + suspension 30.9 T:80

Type: Dropper

Pedals

Trekking-Pedal VP-616 anti-slip

Grips

Ergon GP1 SD

Groupset
Rear Derailleur

Shimano Deore XT M8130-11 LG shadow+

Crank

KTM E-TEAM ISIS 170mm Q16

Shifters

Shimano Deore XT M8130-11 LG

Cassette

Shimano LG400-11 / 11-50

Chain

KMC e11 Sport EPT e-bike

Chain Guide

KTM type 9 for Bosch BDU38

Brakes

Shimano Deore XT M8130-11 LG

Type: Shimano XT Hydraulic Disc

Wheels
Tires

Front: Schwalbe Al Ground Perf. RaceGuard 60-622 Reflex, Rear: Schwalbe Al Ground Perf. RaceGuard 60-622 Reflex

Electric Components
Motor

Bosch PERFORMANCE CX BDU3840 up to 100Nm

Battery

Bosch PowerTUBE 800Wh horizontal

Display

Bosch LED Remote / KIOX 500 TFT Display

Charger

Bosch STANDARD Charger 4A

Accessories
Fenders

SKS A69R PET Trek 28"

Racks

KTM light 60 (snap-it 1.0)
