2026 KTM

MACINA AERA 771 LFC

A 27.5″ aluminum frame hardtail crosscountry e-bike with high-end components.
Compare the full range

Manufacturer Price

€5,499($6,369)
Price History
Weight60.4 lbs
FrameAluminum
SuspensionHardtail, 100mm
ForkFox AWL
Wheels27.5″ Aluminum
Drivetrain1 × 11
GroupsetXT
MotorBosch 600W 85Nm mid-drive
BatteryBosch 750Wh
BrakesShimano XT Hydraulic Disc
View on ktm-bikes.atLearn about KTM
Add to Comparison
Shop with an Expert at Upway
Where to Buy

($6,369)

KTM logoKTM

MACINA AERA 771 LFC

Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Terrain
easyextreme
Handling
nimblestable
MACINA AERA 771 LFC
Other Crosscountry bikes
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

28 mph

MACINA AERA 771 LFC

27 mph

Similar Bikes

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full MACINA AERA model range

View Comparison
Sizing
XS

5'1" – 5'6"

SM

5'4" – 5'9"

MD

5'7" – 6'0"

LG

5'10" – 6'3"

XL

6'0" – 6'5"

🐐 Estimated

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Price History
Geometry
Specs
Build
Frame

Macina Trekking Onroad Alloy6061; PT750Wh Bosch Gen.4 / T-2940

BB Standard: Bosch, Press Fit

Fork

FOX 34 Float AWL 27.5" e-bike 100mm 15x110

Travel: 100mm

Spring Type: Air

Bottom Bracket

Bosch, press-fit

Headset

Acros AICR internal 1.1/8"-1.5" angle limit

Stem

KTM adjust. 0-60° ICR

Handlebar

KTM Team rizer15 680mm

Saddle

Selle Royal Lookin+

Seatpost

KTM Team 30.9/300

Type: Rigid

Pedals

MTB-Pedal flat VPE-527 alloy

Groupset
Rear Derailleur

Shimano Deore XT M8130-11 LG shadow+

Crank

KTM E-TEAM ISIS 170mm Q16

Shifters

Shimano Deore XT M8130-11 LG

Cassette

Shimano LG400-11 / 11-50

Chain

KMC e11 Sport EPT e-bike

Brakes

Shimano Deore XT M8130-11 LG

Type: Shimano XT Hydraulic Disc

Wheels
Rims

KTM Line - DT Swiss 370 CL R28 110/15 SS HY Straight Pull / Ambrosio E30 Trail 28H 584x30TC / DT Hybrid 2.34 straightpull black

Tires

Front: Schwalbe Johnny Watts Perf. Folding 65-584 DD, Rear: Schwalbe Johnny Watts Perf. Folding 65-584 DD

Disc Rotors

Shimano RT64 CL 180 / 180

Electric Components
Motor

Bosch PERFORMANCE CX Gen.4 SMART SYSTEM - 25km/h / 85Nm

Battery

Bosch PowerTUBE 750Wh SMART SYSTEM hor.

Display

Bosch LED remote SMART SYSTEM / Bosch KIOX 300 TFT Display SMART SYSTEM

Charger

Bosch STANDARD Charger 4A SMART SYSTEM

Accessories
Fenders

Racktime Alu 72mm B&M Xeltec

Racks

Racktime light (snap-it 2.0)
