2024 Canyon
Roadlite:ON 5
A 650b / 700c aluminum frame fitness e-bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
€2,499($2,746)| Weight | 35.9 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Rigid |
| Fork | Carbon |
| Wheels | 650b / 700c Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | Deore |
| Motor | Fazua 450W 60Nm mid-drive |
| Battery | Fazua 430Wh |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Roadlite:ON model range
View Comparison< 5'8"
5'6" – 6'0"
5'10" – 6'4"
6'2" +
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
May 2023 · Julian Schwede
Das Canyon Roadlite:ON CF 9 LTD ist ein komplett durchdesigntes E-Bike mit FAZUA Ride 60-Motor. Wir haben getestet, ob es noch mehr als die cleane Optik beherrscht.
(almost) flawless integration
Battery can be charged on or off the bike
Next level in cockpit integration
Inconspicuously integrated trailer and mudguard mounts
Limited adjustability of handlebar and brake ergonomics
Lack of compliance
Skinny tires can get stuck between tram tracks
Mar 2023
Canyon revamps its hybrid ebike line for more versatility & more power with all-new carbon Roadlite:ON, adventure Pathlite:ON & more...
| Frame | Canyon Roadlite:ON, Robust alunimium e-hybrid frame combining a minimalist design with smooth e-bike power., Axle dimension: 12x142 mm, Material: Aluminium (AL) Color: Shadow Grey |
|---|---|
| Fork | Canyon FK0074 CF DISC, Lightweight carbon fork with comfortable, vibration-damping design., Axle dimension: 15X100 mm, Fork steer tube diameter: 1 1/8", Material: Carbon (CF), Weight: 750 g |
| Saddle | SR Royal Essenza, Weight: 288 g |
| Seatpost | Iridium, Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 280 g Type: Rigid |
| Grips | Ergon GA3 |
| Rear Derailleur | Shimano Deore M5100 11s, Cage length: long, Weight: 356 g |
|---|---|
| Crank | Samox EC37F, Number of chainrings: 1 |
| Shifters | Shimano Deore M5100 11s, Weight: 137 g |
| Cassette | Shimano Deore M5100 11s 11-51, Number of sprockets: 11, Range: 11-51 11S |
| Chain | KMC X11 |
| Brakes | Shimano MT200 | Shimano MT200 / UR300, Number of pistons: 2 Type: Hydraulic Disc |
| Rims | Alexrims GX26P, Axle dimension: 15X100 mm, Rotor mount: Center Lock, Rim height: 26 mm | Alexrims GX26P | Shimano MT400 11S, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 26 mm, Inner width: 23 mm |
|---|---|
| Tires | Schwalbe G-One Allround 40 mm, Width: 1.5", Weight: 440 g |
| Disc Rotors | Shimano RT10, Size: 160 mm, Weight: 180 g |
| Motor | Fazua Ride 60 Drive Unit |
|---|---|
| Battery | Fazua Energy 430 |
Last updated June 15
