2023 Canyon
Torque:ON 9
A 27.5″ aluminum frame full suspension enduro e-bike with high-end components.
Compare the full range
Manufacturer Price
€5,999($6,592)| Weight | 52.5 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Full, 175 / 180mm |
| Fork | Fox Factory Float 38 |
| Shock | Fox Float X2 Factory |
| Wheels | 27.5″ Aluminum |
| Drivetrain | 1 × 12 |
| Groupset | GX Eagle, Shimano |
| Motor | Shimano 250W 85Nm mid-drive |
| Battery | Shimano 504Wh |
| Brakes | Hydraulic Disc |
| Seatpost | Dropper |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Torque:ON model range
View Comparison< 5'10"
5'8" – 6'1"
5'11" – 6'4"
6'3" +
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Dec 2023
The Canyon Torque:ON CF8 is an unapologetically big, brash, full-powered e-bike that is meant to be ridden hard!
Carbon frame and mid-upper tier components are a great value at this price point
720 or 900 Wh battery options
Impressive suspension kinematics and geometry keep the bike extremely capable on big features, but is still fun on less aggressive terrain
Very low bottom bracket makes for frequent pedal/frame strikes
Lacks finesse while climbing and descending technical terrain
Feb 2024 · Mick Kirkman
The Torque:ON is the Canyon’s longest travel, hardest charging, biggest battery-ed, most DH-orientated e-bike, but is it simply too much for most UK trails?
All the range and all the capability
Rides way lighter and more reactive than you’d imagine
Super stiff and solid, without being too sharp and edgy
Fantastic handling and low-slung center of gravity
Near flawless parts package
The flat, hard and uncomfy Fizik saddle
Occasional pedal strikes due to low BB
Obviously, you need more than trail center terrain to let this thing rev up
Oct 2023 · Knut Nes
The new Canyon Torque:ON CF was introduced earlier this year. But, as opposed to the new Spectral:ON CF/CFR, the Torque:ON was equipped with the old Shimano EP8 (EP800). Canyon said the Torque:ON was designed to use the new EP8 (EP801), but they...
Aug 2023
With masses of travel, a mullet setup and the option of a 900Wh battery, the Canyon Torque:ON CF looks like a gravity rider's dream e-MTB.
Absolutely unstoppable on the descents
Incredibly plush & supportive suspension
Mullet setup is a winner
Adjustable long-stroke dropper post
Two battery options
Not the most adept technical climber
Needs steep terrain to get the most out of it
This bike deserves tougher tyre casings
Shimano motor is noisy on the descents
May 2023 · Patrick Brady
What has a 250W motor, the ability to go for five hours (or more) and can handle drops that would make elevators cower? That would be the new Torque:ON, a new model from the German company Canyon that bridges the gap between e-bikes and full downhill bikes. With 170mm of travel in the rear and
May 2023
Canyon drops in with all-new Strive:ON CF enduro ebike, Torque:ON CF carbon freeride eMTB & entry-level Grand Canyon e-hardtails...
May 2023 · Simon Kohler
The 2023 Canyon Torque:ON CF 9 comes equipped with a Shimano EP8 motor, huge 900 Wh battery and generous amounts of travel.
Massive range for long days in the saddle
Inspires huge amounts of confidence
Combines excellent composure with a relatively agile handling
Not a great climber in techy sections
Underwhelmed on moderate trails
May 2023
Big days in the e-saddle at the site of the first ever EWS race in Massa Marittima, Italy riding an e-enduro race platform and a self-shuttling park eMTB.
| Frame | Canyon Torque:ON, Aluminium frame, 175mm of rear suspension, award-winning Triple Phase Suspension design, internal battery, Boost 148 rear spacing, post-mount brakes (203 mm). BB Standard: STEPS, Press Fit Hanger Standard: UDH Color: Stealth |
|---|---|
| Fork | FOX 38 Factory Grip2, 180mm, 180mm of front suspension, 27.5 fork, Boost 110 spacing, 38mm stanchions, Kashima coat, air bleeders, floating axle, EVOL Float air spring, Grip2 high and low-speed compression damping adjuster, rebound damping adjuster Travel: 180mm Spring Type: Air |
| Shock | Fox Float X2 Factory, 175 mm travel, 8-click HS & LS compression & rebound adjustment, increased control on quick hits via linear damping. Eye-to-eye length: 250 mm, stroke: 70 mm, Kashima Coat. Travel: 175mm Spring Type: Air |
| Bottom Bracket | STEPS, press-fit |
| Stem | Canyon:ON Stem, 35mm clamp diameter, 40mm length |
| Handlebar | Canyon:ON HB0056 Riser bar, Aluminum, 780mm width, 35mm clamp diameter, 20mm rise |
| Saddle | Canyon SD:ON, Perfect for long rides in a seated position or on steep climbs, extra padding around sit bones, additional rear support prevents you from sliding backwards on steep climbs, chromoly rails, durable nylon composite shell, 290 g |
| Seatpost | Iridium Dropper Post, Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling., Clamp diameter: 30,9 mm, Material: Aluminium (AL) Type: Dropper |
| Grips | Canyon Lock-On, Get the ideal mix of incredible direct feedback and comfort. The grips always stay firmly in place, thanks to the screw-tight clamp. |
| Rear Derailleur | SRAM GX Eagle, 12-speed, Cage Lock and Roller Bearing Clutch technologies, 12-speed, Max cassette size: 52T, Weight: 290 g |
|---|---|
| Crank | Shimano STEPS e-MTB crank arms, Designed for the rigors of E-MTB riding, 24mm spindle, 160mm crank arms |
| Shifters | SRAM GX Eagle, 12-speed, Single-click, E-MTB specific rear deralleur shifter, 12-speed, MatchMaker X clamp, |
| Cassette | SRAM GX Eagle, 12-speed (10-52), Cassette size: 10-52T, Gear range: 520% | SRAM GX XG-1275 12-speed Cassette 10-52 |
| Chain | SRAM X01 Eagle 12-speed | SRAM X01 Eagle 12-speed Chain 126 Links |
| Brakes | SRAM Code RSC 4-piston front brake, SRAM's most powerful and adjustable four-piston brake. Features reach and contact point adjusters | SRAM Code RSC 4-piston rear brake, SRAM's most powerful and adjustable four-piston brake. Features reach and contact point adjusters Type: Hydraulic Disc |
| Rims | DT Swiss H-1700 Spline, 27.5", Front wheel made for the demands of E-MTBs. DT Swiss Hybrid/350 front hub with Boost 110 spacing, aluminum tubeless-ready DT Swiss 27.5" rim, 30mm inner width | DT Swiss H-1700 Spline, 27.5", Rear wheel made for the demands of E-MTBs. DT Swiss Hybrid/350 star ratchet hub with steel freehub, Boost 148 spacing, reinforced DT Hybrid 1 spokes, aluminum tubeless-ready DT Swiss 27.5" rim, 35mm inner width |
|---|---|
| Tires | Maxxis Minion DHF, 27.5x2.5", 3C MaxxTerra compound | Maxxis Minion DHR II, 2.6", EXO+ casing, Tubeless Ready design, 3C MaxxTerra tread compound | Maxxis Minion DHR II EXO+ 3C MaxxTerra WT 27.5" x 2.6" MTB Tyre |
| Disc Rotors | SRAM Centerline rear rotor, 203mm, Stainless steel construction, 12-spoke design reduces distortion, UCI-compliant rounded edges, six-bolt mounting | SRAM Centerline front rotor, 220mm, Maximum stopping power courtesy of 220mm size, stainless steel construction, 12-spoke design reduces distortion, rounded edges are UCI compliant, six-bolt attachment | SRAM Centerline 6-Bolt 220mm Brake Rotor | SRAM Rotor Centerline Brake Rotor 203mm |
| Motor | Shimano Steps EP8 Motor, High-torque motor. Maximum torque: 85 Nm. 3 app-tunable support modes: Eco, Trail, Boost. |
|---|---|
| Battery | Shimano BT-E8035, Lithium-Ion battery, IPX5 water resistant, 3.1 Kg, adaptor for external charging not included. |
| Display | Shimano Steps SC-E7000 Display |
