2023 Canyon

Roadlite:ON 7

A 650b / 700c aluminum frame fitness e-bike with upper mid-range components and shimano hydraulic disc brakes.
Compare the full range

Manufacturer Price

€3,499($4,071)
Weight35.3 lbs
FrameAluminum
Wheels650b / 700c Aluminum
Drivetrain1 × 12
GroupsetXT, SLX
MotorFazua 450W 60Nm mid-drive
BatteryFazua 430Wh
BrakesShimano Hydraulic Disc
View on canyon.comLearn about Canyon
Add to Comparison
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Ride Feel

Based on frame geometry and build specs.

Rider Position
relaxedaggressive
Roadlite:ON 7
Other Fitness bikes
Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full Roadlite:ON model range

View Comparison
Sizing
SM

< 5'9"

MD

5'7" – 6'1"

LG

5'11" – 6'4"

XL

6'3" +

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Reviews
Downtown
Canyon Roadlite:ON CF 9 LTD in review – A master of integration and designer piece

May 2023 · Julian Schwede

Das Canyon Roadlite:ON CF 9 LTD ist ein komplett durchdesigntes E-Bike mit FAZUA Ride 60-Motor. Wir haben getestet, ob es noch mehr als die cleane Optik beherrscht.

Highs

  • (almost) flawless integration

  • Battery can be charged on or off the bike

  • Next level in cockpit integration

  • Inconspicuously integrated trailer and mudguard mounts

Lows

  • Limited adjustability of handlebar and brake ergonomics

  • Lack of compliance

  • Skinny tires can get stuck between tram tracks

Read Review

Bikerumor
Canyon Hybrid eBikes boosted from mullet city Roadlite:ON to SUV adventuring Pathlite:ON

Mar 2023 · Cory Benson

Canyon revamps its hybrid ebike line for more versatility & more power with all-new carbon Roadlite:ON, adventure Pathlite:ON & more...

Read Review

Geometry
Specs
Build
Frame

Canyon Roadlite:ON, Robust alunimium e-hybrid frame combining a minimalist design with smooth e-bike power., Axle dimension: 12x142 mm, Material: Aluminium (AL)

Color: Light Grey

Saddle

SR Royal Essenza, Weight: 288 g

Seatpost

Canyon S25 VCLS 2.0 CF, Material: Carbon, Setback: -2 mm / 10 mm, Technology: VCLS 2.0 | Fliphead, Weight: 235 g

Type: Rigid

Grips

Ergon GA3

Groupset
Rear Derailleur

Shimano DEORE XT M8100, Cage length: long, Weight: 286 g

Crank

Samox EC37F, Number of chainrings: 1

Shifters

Shimano SLX M7100 12s, Weight: 143 g

Cassette

Shimano SLX M7100, Number of sprockets: 12 | Shimano CS-M7100 MTB 12-speed Cassette

Chain

Shimano CN-M7100 12s | Shimano CN-M7100 12-speed Chain 138 Links | Shimano SM-CN910 12-speed Quick-Link Chain Connector

Brakes

Shimano MT200 | Shimano MT200 / UR300​, Number of pistons: 2

Type: Shimano Hydraulic Disc

Wheels
Rims

Alexrims GX26P, Axle dimension: 15X100 mm, Rotor mount: Center Lock, Rim height: 26 mm | Alexrims GX26P, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 26 mm, Inner width: 23 mm

Tires

Schwalbe G-One Allround 40 mm, Width: 1.5", Weight: 440 g | Schwalbe G-One Allround Super Ground 27.5" & 28" Tyre | Schwalbe G-One Bite 27.5" & 28" Gravel Tyre

Disc Rotors

Shimano RT10, Size: 160 mm, Weight: 180 g | Shimano SM-RT10 Brake Rotor

Electric Components
Motor

Fazua Ride 60 Drive Unit

Battery

Fazua Energy 430, 430 Wh

Charger

FAZUA RIDE 60 Charger
