A 27.5″ / 29″ aluminum frame full suspension trail bike with high-end components. Compare the full range
MSRP | $2,599 |
---|---|
Weight | 32.4 lbs |
Suspension | Full |
Travel | 140mm front |
Frame | Aluminum |
Fork | Fox Rhythm Float 34 |
Wheels | 27.5″ / 29″ Aluminum |
Drivetrain | 1 × 12 |
Groupset | NX Eagle |
Brakes | Hydraulic Disc |
Seatpost | Dropper |
For This Bike
Based on frame geometry and build specs. Learn more →
A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills. Learn more
used for climbing
Neuron 6
Similar Bikes
used for descending and sprinting
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more. Learn more →
5'2" – 5'6"
5'4" – 5'10"
5'8" – 6'1"
5'11" – 6'4"
6'3" +
Sep 2023 · Mick Kirkman
Fast and efficient, the Neuron has nailed the remit for a rapid and composed-feeling trail bike
Fast accelerating and quick across the ground on mellower trails
Schwalbe tyres roll rapidly with adequate grip in most conditions
Suspension feels a little hyperactive and overworked on steeper downhill trails
Lock-on grips feel quite hard
Aug 2023 · Pat Donahue
The Canyon Neuron 5 is a fast and efficient trail bike with conservative geometry. This bike has a bit of an old-school attitude and that is exactly what...
Mar 2023
The new 2023 Canyon Neuron trail bike gets every update you could wish for in a modernized mountain bike - lighter, stiffer & more capable than ever
Mar 2023 · Danny Milner
The affordably-priced Canyon Neuron is a versatile, back-to-basics mountain bike, designed to be as adept as clocking up the miles as delivering the smiles on fun singletrack. So does it deliver against those promises? Best mountain bikes: XC, hardtail, trail and enduro for all budgets Best budget full-suspension bikes Need to know Entry-level trail bike with 130mm travel 11 bike range, offering both carbon and alloy-framed options starts at £1,849 Small frame sizes come with 27.5in wheels, larger sizes get 29in wheels Updates include more progressive geometry, integrated protection and a focus on low maintenance The Canyon Neuron was only launched in 2017, but its roots can be traced right back to the brand’s very inception. It was the replacement for the full-suspension Nerve; a bike that was born all the way back in 2002. And it happened to be the first Canyon model we ever tested here at MBR. That bike was the 2011 Nerve XC 5.0, and it featured an alloy frame with 120mm of travel and 26in wheels. It also weighed 12.9kg and cost £1,188 excluding the box and shipping. This new Canyon Neuron might have radically different geometry to its forebear, wheels that are 3in bigger in diameter, and a price and weight that have succumbed a little to middle-aged spread, but it’s still intended to be an affordable, versatile, friendly trail bike that is as approachable for beginners as it is thrilling to experienced riders. Unfortunately the first generation Neuron (at least in my opinion) fell wide of its intended mark. Canyon chose to take a very cautious approach at a time when geometry and sizing was settling down after a period of rapid evolution. Which meant that the head angle was too steep, the seat angle was too slack, the wheelbase was dinky, and the seat tube too long. As a result, the bike was twitchy and unstable on descents, and the steering too light when climbing. Ultimately, the 2017 Canyon Neuron was out of date from the moment it hit the market. Which was a huge shame, because the suspension was excellent, with a smooth, supple response to small bumps while never being overwhelmed by rougher terrain. Canyon Neuron frame So does this updated version correct the mistakes of its predecessor? It’s obvious that the latest bike is an entirely different proposition just by comparing the old and new side-profiles. The seat angle is visibly steeper, the head angle obviously slacker and the reach appreciably longer. To put numbers on these changes, the seat angle is 1.5º steeper, the head angle a similar amount slacker, the seat tubes are around 20mm lower, and the reach has grown by between 10mm and 40mm depending on the frame size. And TLDR; these changes to the geometry transform the Neuron for the better. But before I get to the ride, let’s run through the basics of the range. Available in either carbon or alloy, the Neuron frame delivers 130mm of travel matched with a 140mm travel …Continue reading »
Hyper-fast. Friendly yet rewarding geometry. Excellent value.
Seat tube could be a bit shorter. Saddle is a bit too racy.
Mar 2023
More trail-friendly than a Lux, not as burly as a Spectral, the Neuron is Canyon’s bread and butter mountain bike. How does it respond to getting hit with the Longer/Slacker/More stick?
Mar 2023 · Henry Quinney
Canyon's classic trail bike receives numerous frame and geometry updates.
Mar 2023
The Neuron is now lighter, tougher and more capable than ever
Mar 2023
The Canyon Neuron has received a big overhaul for 2023. So how does it perform on the trail? Read on for our Canyon Neuron review.
Sleek & lightweight frame
Responsive & well-balanced handling
Efficient pedalling performance
Short seat tubes & long dropper post
Fantastic build kit for the money
Firm tyre compound struggles on rocky terrain
FIT4 fork damper lacks sensitivity
Ergon grips creak
Frame | Canyon Neuron, Rugged full-suspension aluminium MTB frame with a perfectly balanced geometry for a confidence inspiring ride., Axle dimension: 12x148 mm, Material: Aluminium (AL) BB Standard: BSA, 73mm, Threaded Hanger Standard: UDH Colors: Alps White; Peak Blues |
---|---|
Fork | FOX 34 Rhythm, Axle dimension: 15x110 mm, Stanchion Diameter: 34 mm, Travel: 140 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 44 mm Spring Type: Air |
Rear Shock | FOX Float DPS Performance |
Bottom Bracket | SRAM BSA DUB, Bottom bracket standard: BSA 73 |
Stem | Iridium Stem, Fork steer tube diameter: 1 1/8" |
Handlebar | Iridium Flatbar, Material: Aluminium, Rise: 5mm, Width for S and XS frames: 740 mm |
Saddle | Selle Italia X3, Gender: Unisex |
Seatpost | Iridium Dropper, Clamp diameter: 30,9 mm, Material: Aluminium (AL) |
Pedals | None included |
Grips | Canyon Lock-On |
Rear Derailleur | SRAM NX Eagle, Cage length: long |
---|---|
Crank | SRAM NX Eagle, Number of chainrings: 1 |
Shifters | SRAM NX Eagle Trigger 12s |
Cassette | SRAM PG-1230 Eagle 11-50 12s, Number of sprockets: 12 |
Chain | SRAM SX Eagle 12s |
Brakes | SRAM DB8 | SRAM Matchmaker Clamp |
Rims | DT Swiss AM LN 370, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Wheelsize: 29" | DT Swiss AM LN 370, Axle dimension: 12x148 mm, Rotor mount: IS 6-bolt, Wheelsize: 29" |
---|---|
Tires | Schwalbe Nobby Nic 29x2.4" bronze skin, Width: 2.4" | Schwalbe Wicked Will 29x2.4" bronze skin, Width: 2.4" |
Disc Rotors | SRAM Centerline Rounded, Size: 180 mm |
