2023 · CanyonNeuron 5

2023 Canyon Neuron 5

A 27.5″ / 29″ aluminum frame full suspension trail bike with upper mid-range components. Compare the full range

Weight33.3 lbs
SuspensionFull, 140mm front
ForkRockShox Recon Silver RL
ShockRockShox Deluxe Select+
Wheels27.5″ / 29″ Aluminum
Drivetrain1 × 12
GroupsetSX Eagle
BrakesHydraulic Disc
View on canyon.comLearn about Canyon
Top Comparison

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear


24 mph

Neuron 5

26 mph

Similar Bikes

Highest gear


Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full Neuron model range

View Comparison

< 5'6"


5'4" – 5'10"


5'8" – 6'1"


5'11" – 6'4"


6'3" +

Rider Fit Notes
  • 5'7", size SM, Just right
Singletrack World
Canyon Neuron AL 6 review

Oct 2023 · Aran Francis

If you just want a no-nonsense mountain bike at an attractive priuce point, the Canyon Neuron AL 6 is a very good answer.

Read Review

Canyon Neuron 5 review

Sep 2023 · Mick Kirkman

Fast and efficient, the Neuron has nailed the remit for a rapid and composed-feeling trail bike

  • Fast accelerating and quick across the ground on mellower trails

  • Schwalbe tyres roll rapidly with adequate grip in most conditions

  • Suspension feels a little hyperactive and overworked on steeper downhill trails

  • Lock-on grips feel quite hard

Read Review

Outdoor Gear Lab
Canyon Neuron 5

Aug 2023 · Pat Donahue

The Canyon Neuron 5 is a fast and efficient trail bike with conservative geometry. This bike has a bit of an old-school attitude and that is exactly what...

Read Review

All-New Canyon Neuron updates modern, more capable do-it-all trail mountain bike

Mar 2023

The new 2023 Canyon Neuron trail bike gets every update you could wish for in a modernized mountain bike - lighter, stiffer & more capable than ever

Read Review

Canyon Neuron 6 (2023) review - MBR

Mar 2023 · Danny Milner

The affordably-priced Canyon Neuron is a versatile, back-to-basics mountain bike, designed to be as adept as clocking up the miles as delivering the smiles on fun singletrack. So does it deliver against those promises? Best mountain bikes: XC, hardtail, trail and enduro for all budgets Best budget full-suspension bikes Need to know Entry-level trail bike with 130mm travel 11 bike range, offering both carbon and alloy-framed options starts at £1,849 Small frame sizes come with 27.5in wheels, larger sizes get 29in wheels Updates include more progressive geometry, integrated protection and a focus on low maintenance  The Canyon Neuron was only launched in 2017, but its roots can be traced right back to the brand’s very inception. It was the replacement for the full-suspension Nerve; a bike that was born all the way back in 2002. And it happened to be the first Canyon model we ever tested here at MBR. That bike was the 2011 Nerve XC 5.0, and it featured an alloy frame with 120mm of travel and 26in wheels. It also weighed 12.9kg and cost £1,188 excluding the box and shipping.  This new Canyon Neuron might have radically different geometry to its forebear, wheels that are 3in bigger in diameter, and a price and weight that have succumbed a little to middle-aged spread, but it’s still intended to be an affordable, versatile, friendly trail bike that is as approachable for beginners as it is thrilling to experienced riders. Unfortunately the first generation Neuron (at least in my opinion) fell wide of its intended mark.  Canyon chose to take a very cautious approach at a time when geometry and sizing was settling down after a period of rapid evolution. Which meant that the head angle was too steep, the seat angle was too slack, the wheelbase was dinky, and the seat tube too long. As a result, the bike was twitchy and unstable on descents, and the steering too light when climbing. Ultimately, the 2017 Canyon Neuron was out of date from the moment it hit the market. Which was a huge shame, because the suspension was excellent, with a smooth, supple response to small bumps while never being overwhelmed by rougher terrain.  Canyon Neuron frame So does this updated version correct the mistakes of its predecessor? It’s obvious that the latest bike is an entirely different proposition just by comparing the old and new side-profiles. The seat angle is visibly steeper, the head angle obviously slacker and the reach appreciably longer. To put numbers on these changes, the seat angle is 1.5º steeper, the head angle a similar amount slacker, the seat tubes are around 20mm lower, and the reach has grown by between 10mm and 40mm depending on the frame size. And TLDR; these changes to the geometry transform the Neuron for the better.  But before I get to the ride, let’s run through the basics of the range. Available in either carbon or alloy, the Neuron frame delivers 130mm of travel matched with a 140mm travel …Continue reading »

  • Hyper-fast. Friendly yet rewarding geometry. Excellent value.

  • Seat tube could be a bit shorter. Saddle is a bit too racy.

Read Review

Canyon Neuron CF9 SL

Mar 2023

More trail-friendly than a Lux, not as burly as a Spectral, the Neuron is Canyon’s bread and butter mountain bike. How does it respond to getting hit with the Longer/Slacker/More stick?

Read Review

First Ride: 2023 Canyon Neuron

Mar 2023 · Henry Quinney

Canyon's classic trail bike receives numerous frame and geometry updates.

Read Review

The Gear Loop
Canyon takes the wraps off its all-new Neuron: the ultimate adventure mountain bike

Mar 2023

The Neuron is now lighter, tougher and more capable than ever

Read Review

99 Spokes on YouTube99 Spokes on YouTube

Canyon Neuron, Rugged full-suspension aluminium MTB frame with a perfectly balanced geometry for a confidence inspiring ride., Axle dimension: 12x148 mm, Material: Aluminium (AL)

BB StandardBSA, 73mm, Threaded

Hanger StandardUDH

ColorsAlps White; Soil Red


Rock Shox Recon Silver RL, Axle dimension: 15x110 mm, Stanchion Diameter: 32 mm, Travel: 140 mm, Fork steer tube diameter: 1 1/8" - 1,5", Weight: 2.50 kg


Spring TypeAir


Rock Shox Deluxe Select +

Spring TypeAir

Bottom Bracket

SRAM BSA DUB, Bottom bracket standard: BSA 73, Weight: 87 g


Iridium Stem, Fork steer tube diameter: 1 1/8"


Iridium Flatbar, Material: Aluminium, Rise: 5mm, Width for S and XS frames: 740 mm


Selle Italia X3, Gender: Unisex, Weight: 295 g


Iridium Dropper, Clamp diameter: 30,9 mm, Material: Aluminium (AL)



None included


Canyon Lock-On

Rear Derailleur



SRAM SX Eagle, Number of chainrings: 1




SRAM PG-1230 Eagle 11-50 12s, Number of sprockets: 12




SRAM Level T

TypeHydraulic Disc


Iridium 30, Axle dimension: 15x110 mm, Rotor mount: Center Lock, Inner width: 30 mm | Iridium 30, Axle dimension: 12x148 mm, Rotor mount: Center Lock, Inner width: 30 mm


Schwalbe Nobby Nic 29x2.4 black skin, Width: 2.4" | Schwalbe Wicked Will 29"x2.4", Width: 2.4"

Disc Rotors

SRAM Centerline Rounded, Size: 180 mm, Weight: 193 g
