Today’s Deals2025 Ari
Cascade Peak Elite
A 29″ aluminum frame full suspension trail bike with upper mid-range components.
Compare the full range
Manufacturer Price
$2,799| Weight | 7.3 lbs (frame) |
|---|---|
| Frame | Aluminum |
| Suspension | Full, 135 / 140mm |
| Fork | DVO Diamond |
| Shock | DVO |
| Wheels | 29″ Aluminum |
| Drivetrain | 1 × 11 |
| Groupset | CUES |
| Brakes | Tektro Gemini Hydraulic Disc |
| Seatpost | Dropper |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Cascade Peak model range
View Comparison5'2" – 5'8"
5'6" – 5'11"
5'10" – 6'3"
6'1" – 6'7"
🐐 Estimated
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
Aug 2024
The Ari Cascade Peak, with it's progressive suspension, responsive handling, and low(ish) weight was a collective favorite in our ...
May 2024 · Robert Johnston
The Cascade Peak sits in Ari’s mountain bike range in the lower price point zone, without sacrificing on features and capability. Learn More.
| Frame | Ari Cascade Peak Full Suspension, Alloy, 135mm travel. UDH derailleur hanger. ISCG-05 mounts. Hanger Standard: UDH Colors: Butterscotch; Black |
|---|---|
| Fork | DVO Diamond D3, 140mm travel, 1.5 inch tapered steer tube, 110mmx15mm boost thru axle, black Travel: 140mm |
| Shock | DVO Opal T2, 210x50, Custom Tuned Travel: 135mm |
| Bottom Bracket | Shimano BB-MT501 |
| Headset | FSA Orbit 1.5 ZS No.57E, internal sealed cartridge bearing, tapered |
| Stem | Ari FRD Charger 35, alloy, 35mm clamp, sizes vary depending on custom fit |
| Handlebar | Ari FRD Charger 35, alloy, 35mm clamp, 780mm wide, 25mm riser, 9 degree back-sweep, 5 degree upsweep |
| Saddle | Selle Italia X3 Boost |
| Seatpost | X-Fusion Manic Dropper Post, 31.6, 125-170mm Travel (Customized through our Ari Custom Setup) Type: Dropper |
| Pedals | Available Separately |
| Rear Derailleur | Shimano CUES RD-U6000, 11-Speed |
|---|---|
| Front Derailleur | N/A |
| Crank | Shimano CUES FC-U6000, 11-Speed, 170mm |
| Shifters | Shimano CUES SL-U6000, 11-Speed |
| Cassette | Shimano CS-LG400, 11-50T, 11-Speed |
| Chain | Shimano CN-LG500 11-Speed |
| Brakes | Tektro Gemini, 4-Piston, 2.3 180/180mm F/R rotors Type: Tektro Gemini Hydraulic Disc |
| Rims | WTB i30, 29, TCS Tubeless Ready, 32h |
|---|---|
| Spokes | 1.8mm (15g) black stainless, brass nipples |
| Front Hub | Bear Pawls Sealed Bearing Front: Boost 110x15 thru axle, Rear: Boost 148x12mm thru Axle, HG |
| Rear Hub | Bear Pawls Sealed Bearing Front: Boost 110x15 thru axle, Rear: Boost 148x12mm thru Axle, HG |
| Tires | Front: Maxxis Minion DHF 29x2.5 WT Exo/Tubeless Ready 60 TPI, Rear: Maxxis Aggressor 29x2.5 Exo/Tubeless Ready 60 TPI |
