MSRP | $4,199 | |
|---|---|---|
Where to Buy | — $1 At | |
Category | Endurance, E-Bike | |
Frame | Aluminum | |
| Aluminum | ||
Wheels | Aluminum | |
Wheel Size | 700c | |
| Rim | ||
| Yamaha 250W 70Nm mid-drive | ||
| Yamaha 500Wh | ||
Drivetrain | ||
Brand Site | ||
Summary | The Yamaha WABASH RT is an aluminum frame endurance e-bike with rim brakes. | |
Ask 99 Spokes
Based on frame geometry and build specs.
Frame | Yamaha Hydroformed Aluminum. Integrated battery. Water bottle boss. Tapered Headtube. Internal shift/brake hose routing Color: Blue Steel | |
|---|---|---|
Fork | Fork One-Piece Aluminum. 12x100mm Thru-Axle. Fender and rack compatible. Internal brake hose routing | |
Headset | Integrated bearing with 30mm of spacers | |
Stem | Yamaha Alloy 4-bolt faceplate. 31.8 diameter. 80mm length (S). 90mm length (M). 100mm length (L) | |
Handlebar | Flare drop. 31.8mm diameter. 44cm width | |
Saddle | Yamaha Off-Road Cro-Mo Rail | |
Seatpost | Alloy 30.9 x 340mm (S), 395mm (M), 440mm (L) with 2-bolt adjustable tilt saddle rail clamp Type: Rigid |
Brakes | Rim Type: Rim |
|---|
Rims | 32-Hole Dual Channel Welded Pin w/ Eyeleted Spoke | |
|---|---|---|
Spokes | Spokes SUS304 | |
Front Hub | Front: 12x100mm TA. Rear: 12x142mm TA with integrated speed sensor | |
Rear Hub | Front: 12x100mm TA. Rear: 12x142mm TA with integrated speed sensor | |
Tires | Maxxis Rambler 700 x 45c TR EXO 120tpi |
Motor | Yamaha PWSeries. ST 3-bolt Mount. Square Taper Spindle. Quad Sensor System with rear hub speed sensor. Weight: 7.71lb. Rated power: 250W (Nominal), 500W (Max.). Max. torque: 70Nm. Max. cadence support: xxxrpm. Max. speed support: 28mph. Support modes: AUTO, ECO+, ECO, STANDARD, HIGH | |
|---|---|---|
Battery | Yamaha 500Wh with Charge-life indicator and Self-diagnosis display.. Side-exiting dock station with anti-vibration mounting plate. Weight 6.61lb. 500Wh 36V. 4-hour charge time | |
Display | Computer control functions include: (4) Power-level control switch, stop watch, distance units, power-level LED on/off, cycling function display items, time adjustment, LED headlamp power on/off, 3-color LED power assist level light indicator. Cycling function display include: speed, average speed, maximum speed, trip distance, odometer, cadence, battery capacity (%) |
