STEPS, press-fit

TRENGA rigid aluminum, length: depending on frame size, steerer clamp diameter: 28.6 mm, handlebar clamp diameter: 31.6 mm, angle: ± 5°

TRENGA, width: 760 mm, handlebar clamp Ø: 31.8 mm, backsweep: 11°

Selle Italia X3 E-Bike Climb Control, ultra-flat profile, lightweight, easy-care microfiber surface

TDE Alloy MTB Platform HPL, Large, safe tread, aluminum pedal body, reflectors

Shimano STEPS FC-M8150, Specially developed for E-MTB, Crank length: 165 mm or 170 mm, depending on frame height, Q-factor: 177 mm, Light and stiff thanks to HOLLOW TECH II design

Shimano Deore XT RD-M8130 SGS, Shadow RD Plus design for optimal chain guidance, optimized for LINKGLIDE, smooth and reliable shifting, derailleur stabilizer to prevent chain slap, more efficient, ball-bearing pulley wheels, largest sprocket max. 50 teeth

Shimano CS-LG700-11, 11-speed LINKGLIDE, gear ratios: 11-13-15-17-20-23-26-30-36-43-50, increased wear resistance

Shimano CN-E8000, HG-X for e-bikes, optimized shifting performance, dirt-repellent design, SIL-TEC treatment for improved durability

Shimano STEPS SM-CDE80, For 53 mm and 56.5 mm chainline, Precise guide adjustment, Compatible chainrings: 38, 36, 34 teeth

Ryde Edge 30OS Disc, stiffer and more stable thanks to asymmetric cross-section, robust yet lightweight, 32 holes, tubeless ready, ETRTO: 30-622

Sapim Leader, Material: Stainless steel, Diameter: 2.0 mm, Color: Black

Schwalbe Magic Mary Evo, size: 29x2.60, top downhill and enduro all-rounder, maximum braking traction and cornering grip, good damping and fast rolling thanks to ADDIX Soft Compound, Tubeless Easy

Shimano STEPS EP800, Max. torque: 85 Nm, Max. power: 500 W, Rated continuous power: 250 W, 20% greater range, Reduced heat generation, Lighter, quieter and more compact, Configurable via E-TUBE PROJECT app

Shimano BT-E8035-L, integrated into the downtube, voltage: 36V, capacity: 14 Ah, energy content: approx. 504 Wh, weight: approx. 2.9 kg

Shimano STEPS EW-SW300, compact on/off switch, semi-integrated in the frame

Shimano STEPS SC-EM800, compact and flat, flexible mounting, shows support modes on 1.6-inch display, can be adjusted by the rider via E-TUBE app, wireless connection via smartphone/tablet

STEPS charger Shi EC-E8004, charging current (max.): 4.6 A, battery charging voltage: 42 V, dimensions: 160 x 70 x 44 mm, weight: approx. 450 g including cable, charging time: 4 h for 504 Wh battery, approx. 4.8 h for 630 Wh battery

Abus PLUS Shimano, battery lock against battery theft, robust X-Plus lock mechanism
