MSRP | $2,090 | |
|---|---|---|
Where to Buy | — $1 At | |
Category | Trail, E-Bike | |
Weight | 57.3 lbs | |
Frame | Aluminum | |
| Suntour XCM | ||
Wheels | Aluminum | |
Wheel Size | 27.5″ | |
| Tektro Dorado Hydraulic Disc | ||
| Bafang 500W 65Nm hub-drive | ||
| 499Wh | ||
| SRAM | ||
Drivetrain | 1 × 9 | |
Suspension | Hardtail | |
Front Travel | 120mm | |
Brand Site | ||
Summary | The Surface 604 Shred is a 27.5″ aluminum frame hardtail trail e-bike with modest components. | |
Ask 99 Spokes
Frame | 6061 Aluminum Alloy | |
|---|---|---|
Fork | SR Suntour XCM 30 Spring Suspension, 120 mm Travel, Compression Adjust with Lockout, Preload Adjust, 100 mm Hub Spacing, 30 mm Stanchions, 9 mm Axle with Quick Release Skewer Travel: 120mm Spring Type: Coil | |
Headset | Integrated, Sealed Cartridge, Straight 1-1/8" | |
Stem | UNO, Aluminum Alloy, 45° Angle, 90 mm Length, 20mm Stack Height, Two 10mm Spacers, One 5mm Spacer | |
Handlebar | Aluminum Alloy, Flat, 700mm Length | |
Saddle | Selle Royal, Royalgel Nebula | |
Seatpost | Alloy, Forged Head Type: Rigid | |
Pedals | Wellgo Aluminum Alloy Platform with Fixed Pins | |
Grips | Velo, Flat Rubber, Locking, Black |
Crank | Samox, Forged Alloy, Sealed Cartridge Bearings, Hollow Spindle, 170mm Length, 38 Tooth Steel Chainring | |
|---|---|---|
Shifters | SRAM Triggers on Right (One-Way High Lever, Three-Shift Low Lever) | |
Cassette | 9 Speed 1x9 SRAM X5 Derailleur, 11-34 Tooth Cassette | |
Brakes | Tektro Dorado HD-E715 Hydraulic Disc with 180mm Rotors, Dual-Piston Calipers, Four-Finger Tektro Levers with Adjustable Reach and Motor Inhibitors Type: Tektro Dorado Hydraulic Disc |
Rims | Double Wall, Aluminum Alloy, 35.5mm Outer Width, 36 Hole, Black | |
|---|---|---|
Spokes | Stainless Steel, 13 Gauge Front and 12 Gauge Rear, Black with Nipples | |
Tires | CST Patrol, 27.5" x 2.8" (71-584) |
Motor | Weight: 9 lbs (4.08 kg), Brand: Bafang RM G360.500.DC, Type: Rear-Mounted Geared Hub, Nominal Output: 500 watts, Peak Output: 750 watts, Torque: 65 Newton meters | |
|---|---|---|
Battery | Weight: 7.1 lbs (3.22 kg), Brand: Samsung 18650, Voltage: 48 volts, Amp Hours: 10.4 ah (Optional 14 ah), Watt Hours: 499.2 wh (Optional 672wh), Chemistry: Lithium-ion | |
Display | Fixed, Adjustable Angle, 3.25" Color, Backlit LCD |
