Bikes up to 60% offWe monitor over 40,000 bikes daily to find the best prices

Today’s Deals
Bike Comparison
    TourRay E 6.02021 R RAYMON
    Recommended
    MSRP
    ($3,666)
    Where to Buy
    —
    $1

    At

    Category
    		Touring, E-Bike
    Weight
    		59.1 lbs
    5.6
    Frame
    		Carbon
    Wheels
    		Aluminum
    Wheel Size
    		650b
    		Tektro Hydraulic Disc
    		Yamaha 250W 70Nm mid-drive
    		Yamaha 500Wh
    		Deore
    Drivetrain
    		1 × 10
    Brand Site

    r-raymon-bikes.com

    Summary
    		The R RAYMON TourRay E 6.0 is a carbon frame touring e-bike with upper mid-range components and tektro hydraulic disc brakes.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Rider Position
    relaxedaggressive
    Terrain
    smoothrugged
    TourRay E 6.0
    Other Touring bikes
    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    TourRay E 6.02021 R RAYMON
    Frame

    27.5", Carbon, Integrated battery

    Fork

    SR SUNTOUR NVX

    Spring Type: Coil

    Stem

    R Raymon 31.8, adjustable

    Handlebar

    R Raymon 31.8 mm, 700 mm, Sweep: 9 °, Rise: 15 mm

    Saddle

    R Raymon Ergo

    Seatpost

    R Raymon, 30.9 mm, Patent

    Type: Rigid

    Pedals

    R Raymon, Alloy

    Grips

    R Raymon Ergo, Lock-on grips

    Groupset
    Rear Derailleur

    Shimano Deore, RD-M4120, Shadow, 10-S

    Shifters

    Shimano Deore, SL-M4100, Rapidfire Plus, 10-speed

    Cassette

    Shimano CS-M4100, 11-42 T

    Chain

    KMC e10S

    Brakes

    Front: Tektro HD-M500, 2-piston, Hydraulic disc brake, Rear: Tektro HD-M500, 2-piston, Hydraulic disc brake

    Type: Tektro Hydraulic Disc

    Wheels
    Rims

    Rim: Mach1 Trucky30, Front Hub: R Raymon MD-JA159F, 9x100mm, Rear Hub: R Raymon MD-JA251R, 9x141mm

    Tires

    Continental CONTACT Plus City, Reflex, 55-584, 27.5x2.2

    Electric Components
    Motor

    Yamaha PW-ST, 250W, 70Nm

    Battery

    Yamaha ML500, 500 Wh, 36 V

    Display

    Yamaha Display C, LCD-Display, Bluetooth

    Charger

    Yamaha rapid charger, 4 A

    Accessories
    Lights

    Front: Herrmans MR4, 40 lx, Rear: AXA Blueline E

    Fenders

    Eurofender Tempo 65

    Racks

    R Raymon Tour, MIK
