    FullRay 130E 5.02022 R RAYMON
    Recommended
    MSRP
    ($4,217)
    Where to Buy
    —
    $1

    At

    Category
    		Trail, E-Bike
    Weight
    		53.6 lbs
    4.7
    Frame
    		Aluminum
    		Suntour XCR Air
    		Suntour
    Wheels
    		Aluminum
    Wheel Size
    		29″
    		Tektro Hydraulic Disc
    		Yamaha 250W 70Nm mid-drive
    		Yamaha 500Wh
    		Tektro EDRIVE 9
    Drivetrain
    		1 × 9
    Suspension
    		Full
    Front Travel
    		130mm
    Rear Travel
    		130mm
    Brand Site

    r-raymon-bikes.com

    Summary
    		The R RAYMON FullRay 130E 5.0 is a 29″ aluminum frame full suspension trail e-bike with upper mid-range components.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    FullRay 130E 5.0
    Other Trail bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    30 mph

    FullRay 130E 5.0

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    FullRay 130E 5.02022 R RAYMON
    Frame

    29", Alloy 6061, Integrated battery, Boost, 130 mm

    Fork

    SR SUNTOUR XCR34 Boost LOR, remote lockout, Air, 130 mm, tapered

    Travel: 130mm

    Spring Type: Air

    Shock

    SR SUNTOUR Raidon R, Air, 210x55 mm

    Travel: 130mm

    Headset

    R Raymon ZS44/ZS56

    Stem

    R Raymon 31.8, 7 °, Ahead

    Handlebar

    R Raymon Riser 31.8 mm, 780 mm, Sweep: 6 °, Rise: 15 mm

    Saddle

    R Raymon MTB

    Seatpost

    R Raymon, 31.6 mm, 350 mm, Patent

    Type: Rigid

    Pedals

    R Raymon, aluminum

    Grips

    R Raymon MTB, Lock-on grips

    Groupset
    Rear Derailleur

    Tektro RD-M350, 9-S

    Crank

    R Raymon, Narrow Wide, 38 T

    Shifters

    Tektro SL-M350R

    Cassette

    Tektro CS-M350, 11-46 T

    Chain

    KMC e9S

    Chain Guide

    Direct Mount

    Brakes

    Front: Tektro HD-M280, 2-piston, Hydraulic disc brake, Rear: Tektro HD-M280, 2-piston, Hydraulic disc brake

    Type: Tektro Hydraulic Disc

    Wheels
    Rims

    Front: Rim: Mach 1 650E, With eyelets, Tubeless ready / Hub: R Raymon DA210F, 6-hole, 15x110 mm, thru axle, Rear: Rim: Mach 1 650E, With eyelets, Tubeless ready / Hub: R Raymon DA210R, 6-hole, 12x148 mm, thru axle

    Tires

    Continental Cross King, 58-622, 29, 2.3

    Disc Rotors

    Tektro TR24, 180 mm, 6-hole

    Electric Components
    Motor

    Yamaha PW-ST, 250 W, 70 Nm

    Battery

    Yamaha ML500, 500 Wh, 36 V

    Display

    Yamaha Display A, LCD-Display, Micro-USB

    Charger

    Yamaha rapid charger, 4 A
