MSRP | $8,999 | |
|---|---|---|
Where to Buy | — $1 At | |
Category | Race | |
Frame | Carbon | |
| Carbon | ||
Wheels | Carbon | |
Wheel Size | 700c | |
| SRAM RED Hydraulic Disc | ||
| RED AXS | ||
Drivetrain | 2 × 12 Electronic | |
Power Meter | Red AXS | |
Brand Site | ||
Summary | The Polygon HELIOS A0 AXS is a carbon frame race bike with ultra high-end components and sram red hydraulic disc brakes. | |
Ask 99 Spokes
Based on frame geometry and build specs.
Frame | carbon BB Standard: T47, Threaded Color: Sunset Rush | |
|---|---|---|
Fork | ACX PERFORMANCE UCI APPROVED | |
Bottom Bracket | SRAM DUB T47 85.5 | |
Headset | INTEGRATED (IS) SEALED BEARING FOR OS HEAD TUBE, IS 52/28.6 | IS 52/40 | |
Handlebar | LINC CARBON, W: 400mm (XXXS, XXS, XS) / 420mm (S, M) / 440mm (L, XL), BB: 31.8mm, R/D: -134.2 mm (XXXS, XXS, XS) / -138.2mm (S, M, L, XL), B/R: 92.5mm (XXXS, XXS, XS) / 89.7mm (S, M, L, XL) | |
Saddle | FIZIK VENTO ANTARES R3, KIUM ø 7mm | |
Seatpost | CARBON AERO, DxL: AERO 35 x 351mm Type: Rigid |
Rear Derailleur | SRAM RED AXS E1 DIRECT ATTACH | |
|---|---|---|
Crank | SRAM RED E1 48/35T POWER METER | |
Power Meter | SRAM RED E1 48/35T POWER METER | |
Shifters | SRAM RED AXS E1, 2x12-SPEED | |
Cassette | SRAM RED XG-1290 E1 10-33T XDR | |
Chain | SRAM RED E1 W/ POWERLOCK 12-SPEED | |
Brakes | SRAM RED HYDRAULIC DISC Type: SRAM RED Hydraulic Disc | |
Brake Levers | SRAM RED |
Rims | CARBON 622-25 20H FOR TYRE 622-30/62 DISC TUBELESS READY | |
|---|---|---|
Spokes | F: SAPIM CX-SPRINT NDS:276mm DS:274mm / R: SAPIM CX-SPRINT NDS:276mm DS:272mm | |
Front Hub | ALLOY THRU AXLE 12x100mm 20H SEALED BEARINGS CENTER LOCK | |
Rear Hub | ALLOY THRU AXLE 12x142mm 20H SEALED BEARINGS CENTER LOCK | |
Tires | GOODYEAR VECTOR R SW 700x30C | |
Disc Rotors | SRAM PACELINE X F:160mm / R:140mm CENTER LOCK |
