MSRP | $549 | |
---|---|---|
Where to Buy | — $1 At | $549 At Trek |
Category | General Youth | General Youth |
Weight | 19.0 lbs | 21.1 lbs |
Aluminum | ||
Fork | Steel | Aluminum |
Wheels | Aluminum | Aluminum |
Wheel Size | 12″ | 24″ |
Brakes | Coaster | Rim |
Groupset | microSHIFT Acolyte | |
Drivetrain | Single-speed | 1 × 8 |
Brand Site | ||
Summary | The Merida MATTS J12 is a 12″ general youth bike with coaster brakes. |
Frame | MATTS JUNIOR 12 | Alpha Silver Aluminum, 24'' |
---|---|---|
Fork | Rigid steel Fork | Wahoo 24'' alloy, V-brake bosses, ThruSkew 5mm QR |
Bottom Bracket | Sealed cartridge, 68mm | |
Headset | VP H721 | Integrated, sealed cartridge bearings |
Stem | Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length | |
Handlebar | MERIDA, 440mm width, 120mm rise | Bontrager alloy, 31.8mm, 15mm rise, 580mm width |
Saddle | MERIDA kid little | Kids' padded, integrated seatpost, Blendr light mount, 31.6x270mm |
Seatpost | MERIDA JR, 22.2mm diameter, 0mm setback | |
Pedals | Wellgo, LU-P17 | Kids' Satellite, 9/16 thread |
Grips | Size: 24" wheel, Kids' grip, 108mm width, lock-on; Size: 24" wheel, Kids' grip, 110mm width; Size: 24" wheel, Kids' grip, 108mm width |
Rear Derailleur | microSHIFT Acolyte M5180S, 34-38T max cog | |
---|---|---|
Crank | ACE Single, 24 teeth | Alloy, 28T steel ring, chainguard, 127mm length |
Shifters | microSHIFT Acolyte SL-M6285, 8 speed | |
Cassette | KT, 16 teeth, 1 speed | microSHIFT Acolyte H083, 11-38, 8 speed |
Chain | KMC Z410 | KMC Z8 |
Chain Guide | attached | |
Brakes | Tektro 985A caliper / attached | Alloy linear-pull |
Brake Levers | APSE BL-01 alloy | Kids' alloy brake lever, black |
Rims | MERIDA JR | Alloy 24'', 28h |
---|---|---|
Spokes | Steel UCP | |
Front Hub | KT KT134 / KT KT305R coaster | Formula alloy, 100mm ThruSkew |
Rear Hub | KT KT134 / KT KT305R coaster | Formula FM32 alloy, 135x5mm |
Tires | Inova IA-2603, 12x2.125", wire | Bontrager Connection Comp, wire bead, 30 tpi, 24x2.00'' |
