    eSPRESSO EP8-EDITION EQ2022 Merida
    Recommended
    MSRP
    Where to Buy
    —
    $1

    At

    Category
    		Hybrid, E-Bike
    7.4
    Frame
    		Aluminum
    		Suntour NCX
    Wheels
    		Aluminum
    Wheel Size
    		700c
    		Shimano Deore Hydraulic Disc
    		Shimano 85Nm mid-drive
    		Shimano 630Wh
    		Deore
    Drivetrain
    		1 × 11
    Suspension
    		Hardtail
    Front Travel
    		63mm
    Brand Site

    merida-bikes.com

    Summary
    		The Merida eSPRESSO EP8-EDITION EQ is a 700c aluminum frame hybrid e-bike with upper mid-range components and shimano deore hydraulic disc brakes.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    30 mph

    eSPRESSO EP8-EDITION EQ

    Highest gear

    (descending)

    Geometry
    Specs
    eSPRESSO EP8-EDITION EQ2022 Merida
    Frame

    eSPRESSO LITE III, material: aluminium, 700x50C (with fender) max. wheelsize, 142x12mm axle standard, intube

    BB Standard: BSA, Threaded

    Tire Clearance: 50c

    Fork

    SR Suntour NCX LO, Air, 63mm suspension travel, Tapered, 700x50C max. wheelsize

    Travel: 63mm

    Spring Type: Air

    Bottom Bracket

    BSA, threaded

    Headset

    MERIDA 8155

    Handlebar

    MERIDA EXPERT TK, material: aluminium, 660mm width, 15mm rise

    Saddle

    MERIDA EXPERT TK, V-mount

    Seatpost

    MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback

    Type: Rigid

    Pedals

    VP VPE-889

    Groupset
    Rear Derailleur

    Shimano Deore M5100, SGS

    Crank

    Samox NWP203, 38 teeth

    Shifters

    Shimano Deore M5100

    Cassette

    Shimano M5100, 11-51 teeth, 11 speed

    Chain

    KMC e11S EPT

    Chain Guide

    Sunnywheel SW-CG-173A

    Brakes

    Shimano Deore T6000, 2 piston

    Type: Shimano Deore Hydraulic Disc

    Wheels
    Rims

    MERIDA COMP TK, 20mm inner width, material: aluminium

    Spokes

    Black stainless

    Front Hub

    Shimano Deore, 100x15mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock

    Rear Hub

    Shimano Deore, 100x15mm width front hub, 32 spoke holes, Centerlock, 142x12mm width rear hub, 36 spoke holes, Centerlock

    Tires

    Continental Contact Cruiser, 622-50, wire, reflecting line

    Disc Rotors

    Shimano RT30 / Shimano RTEM300, 180 mm

    Electric Components
    Motor

    Shimano EP8, 85Nm

    Battery

    Shimano E8036, 630Wh

    Display

    Shimano SC-E5003

    Accessories
    Fenders

    Sunnywheel SW-FA311-60E1 (MSB)

    Racks

    MERIDA MIK HD, Spring clip, Spanninga rear light

    Lock

    Abus 5650 LH-3 lock

    Stand

    Massload CL-KA98
