    eSPRESSO CC XT-EDITION EQ2022 Merida
    Recommended
    MSRP
    Where to Buy
    —
    $1

    At

    Category
    		Hybrid, E-Bike
    7.9
    Frame
    		Aluminum
    		Suntour MOBIE
    Wheels
    		Aluminum
    Wheel Size
    		650b
    		Shimano Deore Hydraulic Disc
    		Shimano 85Nm mid-drive
    		Shimano 630Wh
    		XT
    Drivetrain
    		1 × 12
    Suspension
    		Hardtail
    Front Travel
    		75mm
    Brand Site

    merida-bikes.com

    Summary
    		The Merida eSPRESSO CC XT-EDITION EQ is a 650b aluminum frame hybrid e-bike with upper mid-range components and shimano deore hydraulic disc brakes.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    31 mph

    eSPRESSO CC XT-EDITION EQ

    Highest gear

    (descending)

    Geometry
    Specs
    eSPRESSO CC XT-EDITION EQ2022 Merida
    Frame

    eSPRESSO CC LITE II, material: aluminium, 27,5x2,25" max. wheelsize, 135x9mm axle standard, internal

    BB Standard: BSA, Threaded

    Fork

    SR Suntour Mobie A32 NLO, Coil, 75mm suspension travel, lockout, 27,5x2,4" max wheelsize

    Travel: 75mm

    Spring Type: Coil

    Bottom Bracket

    BSA, threaded

    Headset

    Acros Trekking

    Handlebar

    MERIDA EXPERT TK, material: aluminium, 680mm width, 15mm rise

    Saddle

    MERIDA EXPERT TK, V-mount

    Seatpost

    MERIDA EXPERT TK, 30.9mm diameter, 15mm setback, 40mm seatpost suspension travel

    Type: Suspension

    Pedals

    VP VPE-889

    Groupset
    Rear Derailleur

    Shimano XT M8100, SGS

    Crank

    Samox NWP203, 38 teeth

    Shifters

    Shimano XT

    Cassette

    Shimano M6100, 10-51 teeth, 12 speed

    Chain

    KMC e12T EPT

    Chain Guide

    Sunnywheel SW-CG-173A

    Brakes

    Shimano Deore T6000, 2 piston

    Type: Shimano Deore Hydraulic Disc

    Wheels
    Rims

    MERIDA COMP TK, 20mm inner width, material: aluminium

    Spokes

    Black stainless

    Front Hub

    Shimano MT400 / Shimano MT500, 100x15mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock

    Rear Hub

    Shimano MT400 / Shimano MT500, 100x15mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock

    Tires

    Maxxis Crossmark II, 27.5x2.25", wire, reflecting line

    Disc Rotors

    Shimano RT30 / Shimano RTEM300, 180 mm

    Electric Components
    Motor

    Shimano EP8, 85Nm

    Battery

    Shimano E8036, 630Wh

    Display

    Shimano SC-E6100

    Accessories
    Fenders

    Sunnywheel SW-FA-311-65A(MSB)

    Racks

    MERIDA MIK HD, Spring clip, Spanninga rear light

    Lock

    Abus 4650 XL

    Stand

    Atranvelo 1219-PC-7
