MSRP | ||
|---|---|---|
Where to Buy | — $1 At | |
Category | Hybrid, E-Bike | |
Frame | Aluminum | |
Wheels | Aluminum | |
Wheel Size | 700c | |
| Shimano Hydraulic Disc | ||
| Shimano 250W 60Nm mid-drive | ||
| 750Wh | ||
| Shimano | ||
Drivetrain | Internally Geared Hub | |
Suspension | Hardtail | |
Front Travel | 63mm | |
Brand Site | ||
Summary | The Merida eSPRESSO 775 EQ is a 700c aluminum frame hybrid e-bike with modest components and shimano hydraulic disc brakes. | |
Ask 99 Spokes
Frame | eSPRESSO LITE IV HG, material: aluminium, 700x50C (with fender) max. wheelsize, 142x12mm axle standard, intube BB Standard: BSA, Threaded Tire Clearance: 50c | |
|---|---|---|
Fork | SR Suntour NEX E25, Coil, 63mm suspension travel, 700x52C max wheelsize Travel: 63mm Spring Type: Coil | |
Bottom Bracket | BSA, threaded | |
Headset | MERIDA 8156 | |
Handlebar | MERIDA EXPERT TK, material: aluminium, 660mm width, 15mm rise | |
Saddle | MERIDA EXPERT TK, V-mount | |
Seatpost | MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback Type: Rigid | |
Pedals | VP VPE-891 |
Crank | Shimano CRE61, 38 teeth | |
|---|---|---|
Shifters | Shimano SW-E6010-R | |
Cassette | Shimano CS-C7000, 27 teeth | |
Chain | KMC Z1eHX EPT | |
Chain Guide | Sunnywheel SW-CG-173A | |
Brakes | Shimano MT400, 2 piston Type: Shimano Hydraulic Disc |
Rims | MERIDA COMP TK, 20mm inner width, material: aluminium | |
|---|---|---|
Spokes | Black stainless | |
Front Hub | Shimano M4050 / Shimano Nexus Inter-5E, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock | |
Rear Hub | Shimano M4050 / Shimano Nexus Inter-5E, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 36 spoke holes, Centerlock | |
Tires | Continental Contact Cruiser, 622-50, wire, reflecting line | |
Disc Rotors | Shimano RT30 / Shimano RTEM300, 180 mm |
Motor | Shimano E6100, 60Nm | |
|---|---|---|
Battery | Simplo Internal Battery, 750Wh | |
Display | Shimano SC-E6100 |
Fenders | Sunnywheel SW-FA311-60E1 (MSB) | |
|---|---|---|
Racks | MERIDA MIK HD, Spring clip, Spanninga rear light | |
Lock | Abus 5650 LH-3 lock | |
Stand | Massload CL-KA98 |
