    eOne-Twenty 900-E2019 Merida
    Recommended
    MSRP
    Where to Buy
    —
    $1

    At

    Category
    		Trail, E-Bike
    Weight
    		49.4 lbs
    6.7
    Frame
    		Aluminum
    		RockShox Pike RCT3
    		RockShox Deluxe
    Wheels
    		Aluminum
    Wheel Size
    		27.5″
    		Shimano XT Mechanical Disc
    		Shimano 250W 70Nm mid-drive
    		Shimano 504Wh
    		XT Di2
    Drivetrain
    		1 × 11 Electronic
    Suspension
    		Full
    Front Travel
    		130mm
    Rear Travel
    		120mm
    Brand Site

    merida-bikes.com

    Summary
    		The Merida eOne-Twenty 900-E is a 27.5″ aluminum frame full suspension trail e-bike with high-end components and shimano xt mechanical disc brakes.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    eOne-Twenty 900-E
    Other Trail bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    25 mph

    eOne-Twenty 900-E

    Highest gear

    (descending)

    Geometry
    Specs
    eOne-Twenty 900-E2019 Merida
    Frame

    Aluminum

    Fork

    RockShox Pike RCT3, Air, 110x15mm

    Travel: 130mm

    Spring Type: Air

    Shock

    RockShox Deluxe RT, platform, trunnion mount

    Travel: 120mm

    Headset

    FSA No. 55EP Neck

    Stem

    Merida Expert eTR, 35mm diameter, 0° stem angle

    Handlebar

    Merida Expert eTR, 20mm rise, 780mm width

    Saddle

    Merida Expert CC

    Seatpost

    RockShox Reverb, 100mm travel (S), 150mm travel (M, L, XL)

    Type: Dropper

    Pedals

    VP VPE-537

    Grips

    Merida Expert EC

    Groupset
    Rear Derailleur

    Shimano XT Di2

    Front Derailleur

    N/A

    Crank

    Shimano E8050, hollow, 170mm

    Shifters

    Shimano XT Di2

    Cassette

    Shimano M8000, 11-46 tooth, 11-speed

    Chain

    KMC X11e

    Chain Guide

    N/A

    Brakes

    Shimano XT with RT86 rotors (203mm front and rear)

    Type: Shimano XT Mechanical Disc

    Brake Levers

    Shimano XT

    Wheels
    Rims

    DT Swiss Spline HX1501 wheelset, 35mm inner width

    Spokes

    DT Swiss Spline HX1501 wheelset

    Front Hub

    DT Swiss Spline HX1501 wheelset, Centerlock, 110x15mm front, 148x12mm rear

    Rear Hub

    DT Swiss Spline HX1501 wheelset, Centerlock, 110x15mm front, 148x12mm rear

    Tires

    Front: Maxxis DHR II, 27.5 x 2.8", folding, 3C, EXO, TR, Rear: Maxxis Rekon, 27.5 x 2.8", folding, 3C, EXO, TR

    Electric Components
    Motor

    Shimano Steps E8000, max output 70Nm (250W)

    Battery

    Shimano E8010 with Abus key lock

    Remote

    Shimano SC-E8000

    Display

    Shimano SC-E8000
