MSRP | $4,199 | |
|---|---|---|
Where to Buy | — $1 At | $4,199 At Canyon |
Category | Trail, E-Bike | Trail |
Weight | 48.6 lbs | 34.9 lbs |
| Carbon | ||
Fork | RockShox Revelation RC | Fox Performance Elite Float 36 |
Shock | RockShox Deluxe | Fox Float DHX Factory |
Wheels | Aluminum | Aluminum |
| 27.5″ | 29″ / 27.5″ | |
Brakes | Mechanical Disc | Hydraulic Disc |
| Shimano 250W 70Nm mid-drive | ||
| Shimano 504Wh | ||
Groupset | XT, SLX | XT, SLX |
Drivetrain | 1 × 11 | 1 × 12 |
Suspension | Full | Full |
Front Travel | 130mm | 150mm |
Rear Travel | 120mm | 140mm |
Brand Site | ||
Summary | The Merida eONE-TWENTY 800 is a 27.5″ full suspension trail e-bike with high-end components and mechanical disc brakes. | |
Based on frame geometry and build specs.
Frame | eONE-TWENTY | Canyon Spectral CF, Full-carbon frame with optimised stiffness and compliance. Convertable wheelsize and geometry adjustment. Category 4 strength., Axle dimension: 12x148 mm, Material: Carbon (CF) |
|---|---|---|
Fork | Rock Shox Revelation RC, Air, 130mm suspension travel, Tapered Travel: 150mm Spring Type: Air | FOX 36 Performance Elite, Axle dimension: 15x110 mm, Stanchion Diameter: 36 mm, Travel: 150 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 44 mm, Weight: 5.18 lbs Travel: 150mm Spring Type: Air |
Shock | Rock Shox Deluxe RT, platform | FOX DHX Factory, Spring: 350 |
Bottom Bracket | Shimano BSA BB52, Bottom bracket standard: BSA HT2 68/73, Weight: 0.22 lbs | |
Headset | FSA NO.55EP neck, 2191017484 | |
Stem | Merida Expert eTR, 35mm diameter, 0° stem angle | Canyon G5, Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails., Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm, Material: Aluminium (AL) |
Handlebar | MERIDA Expert eTR, 780mm width, 20mm rise | Canyon G5, G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability., Clamping diameter: 31,8 mm, Width: 780 mm, Rise: 30 mm |
Saddle | MERIDA Comp CC | Ergon SM10 Enduro Comp, Gender: Unisex, Weight: 0.58 lbs |
Seatpost | MERIDA EXPERT TR, 30.9mm diameter, 0 SB, S: 100mm travel seatpost - M/L/XL 125mm travel seatpost, | Canyon SP0070-01, Air cartridge. Cable actuated., Travel: Dependent on frame size (see component geometry table.), Clamp diameter: 34,9 mm, Material: Aluminium (AL), Weight: 1.50 lbs |
Pedals | VP, VPE-537 | None included |
Grips | Merida Expert EC | Canyon G5 |
Rear Derailleur | Shimano XT M8000 Shadow+ | Shimano DEORE XT M8100, Cage length: long, Weight: 0.63 lbs |
|---|---|---|
Front Derailleur | no | |
Crank | Shimano CRE80-B, 34 teeth | Shimano SLX M7120, Number of chainrings: 1 |
Shifters | no / Shimano SLX 11 | Shimano DEORE XT M8100, Weight: 0.29 lbs |
Cassette | Shimano M7000, 11-46 teeth, 11 speed | Shimano SLX M7100, Number of sprockets: 12 |
Chain | KMC X11e | Shimano CN-M6100 |
Chain Guide | Shimano SM-CDE80 | Canyon EP1266-01 ISCG05 Plate | Canyon GP0293-02 |
Brakes | Shimano SLX | Shimano DEORE XT M8120, Number of pistons: 4 |
Brake Levers | attached |
Rims | MERIDA Expert TP, 38mm inner width | DT Swiss E1900, Axle dimension: 12x148 mm, Rotor mount: IS 6-bolt, Weight: 2.47 lbs | DT Swiss E1900, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Weight: 2.21 lbs |
|---|---|---|
Spokes | Black stainless | |
Front Hub | Joytech D791SB, 110x15mm width, 32 spoke holes, 6 bolt / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock | |
Rear Hub | Joytech D791SB, 110x15mm width, 32 spoke holes, 6 bolt / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock | |
Tires | Maxxis DHR II, 27.5x2.8 ", fold, 3C EXO TR | Maxxis Assegai, Width: 2.5", Weight: 2.25 lbs | Maxxis Minion DHR II Exo+, Width: 2,4", Weight: 2.38 lbs |
Disc Rotors | Shimano SM-RT76, Size: 203 mm, Weight: 0.42 lbs |
Motor | Shimano E8000, 70Nm | |
|---|---|---|
Battery | Shimano E8010, 504 Wh | |
Display | Shimano SC-E8000 |
