Compare: 2026 Merida eONE-EIGHTY 500

Bikes up to 60% offWe monitor over 40,000 bikes daily to find the best prices

Bike Comparison

Only show differences

	eONE-EIGHTY 5002026 Merida	Recommended

MSRP	($7,712)
Where to Buy	— $1 At
Category	Enduro, E-Bike
	5.8
Frame	Aluminum
	RockShox ZEB
	RockShox Vivid
Wheels	Aluminum
Wheel Size	29″ / 27.5″
	SRAM Hydraulic Disc
	Bosch 600W 85Nm mid-drive
	Bosch 800Wh
	CUES
Drivetrain	1 × 10
Suspension	Full
Front Travel	180mm
Rear Travel	180mm
Brand Site	merida-bikes.com
Summary	The Merida eONE-EIGHTY 500 is a 29″ / 27.5″ aluminum frame full suspension enduro e-bike with mid-range components.

Ask 99 Spokes

Want to ask an actual human?

Get free advice from an Upway E-bike Expert

Similar Bikes

Insights

Ride Feel

Based on frame geometry and build specs.

Terrain

easyextreme

Handling

nimblestable

eONE-EIGHTY 500

Other Enduro bikes

Gear Range

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

27 mph

eONE-EIGHTY 500

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Geometry

Specs

	eONE-EIGHTY 5002026 Merida

Frame	eONE-EIGHTY LITE, material: Aluminum, 180mm suspension travel, 29” x 2,6” max. wheelsize, 148x12mm axle standard, intube * BB Standard: BSA, Threaded
Fork	Rock Shox Zeb eMTB, Air, 180mm suspension travel, Tapered, 44mm fork offset, 29x2.6" max wheelsize Travel: 180mm Spring Type: Air
Shock	Rock Shox Vivid Base Travel: 180mm
Bottom Bracket	BSA, threaded
Headset	Acros ICR MERIDA EXTERNAL neck w/ Blocklock
Stem	MERIDA EXPERT eTR II, material: aluminium, 35mm diameter, 0° stem angle, Supernova mount, 40 mm all sizes
Handlebar	MERIDA COMP TR II, material: aluminium, 780mm width, 35mm rise
Saddle	MERIDA COMP SL, V-mount, incl. MERIDA minitool
Seatpost	MERIDA EXPERT TR II, 34.9mm diameter, 0mm setback, travel seatpost: 125mm (XS), 150mm (S), 170mm (M), 200mm (L), 230mm (XL) Type: Dropper
Pedals	VP VPE-533

Groupset

Rear Derailleur	Shimano CUES U6000, GS
Crank	FSA Direct Mount Steel Chainring, 36 teeth
Shifters	Shimano SL -MT500-L / Shimano CUES U6000-10
Cassette	Shimano Cues LG400, 11-48 teeth, 10 speed
Chain	Shimano LG500
Brakes	SRAM DB4 stealth, 4 piston Type: SRAM Hydraulic Disc

Wheels

Rims	MERIDA EXPERT TR II, 110x15mm width front hub, 148x12mm width rear hub, 28mm inner width, material: aluminium, Tubeless ready (tubeless tape and valves not included), front 29", rear 27.5"
Spokes	Black stainless, black nipples
Front Hub	Shimano TC500-B / Shimano TC500-HM-B, 15x100mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Rear Hub	Shimano TC500-B / Shimano TC500-HM-B, 15x100mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 32 spoke holes, Centerlock
Tires	Front: Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip, Rear: Maxxis Minion DHR II, 27.5x2.4 ", fold, 3C DD TR MaxxTerra
Disc Rotors	SRAM CenterLine, 200mm

Electric Components

Accessories

Lights	Lezyne Hekto StVZO E350+ Reverse / USB REAR Light CG-214RG, reverse MERIDA Custom Mount
Fenders	RF-001 mini fender
