    eBIG.TOUR 475 EQ2022 Merida
    Recommended
    MSRP
    Where to Buy
    —
    $1

    At

    Category
    		Commuter, E-Bike
    7.4
    Frame
    		Aluminum
    		Suntour XCM
    Wheels
    		Aluminum
    Wheel Size
    		29″
    		Shimano Hydraulic Disc
    		Shimano 85Nm mid-drive
    		750Wh
    		Deore
    Drivetrain
    		1 × 10
    Suspension
    		Hardtail
    Front Travel
    		100mm
    Brand Site

    merida-bikes.com

    Summary
    		The Merida eBIG.TOUR 475 EQ is a 29″ aluminum frame commuter e-bike with upper mid-range components and shimano hydraulic disc brakes.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from an Upway E-bike Expert

    Shop with an Expert
    Similar Bikes
    Insights
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    27 mph

    eBIG.TOUR 475 EQ

    Highest gear

    (descending)

    Geometry
    Specs
    eBIG.TOUR 475 EQ2022 Merida
    Frame

    eBIG.TOUR LITE IV, material: aluminium, 29x2.35" without fender max./ 29"x2.25" with fender max. wheelsize, 148x12mm axle standard, intube

    BB Standard: BSA, Threaded

    Fork

    SR Suntour XCM34-Boost LOR DS, 100mm, Tapered, 51mm fork offset, 29x2.4" max wheelsize

    Travel: 100mm

    Spring Type: Coil

    Bottom Bracket

    BSA, threaded

    Headset

    MERIDA 8155

    Handlebar

    MERIDA EXPERT CC, material: aluminium, 720mm width, 10mm rise

    Saddle

    MERIDA EXPERT TK, V-mount

    Seatpost

    MERIDA EXPERT CC, material: aluminium, 34.9mm diameter, 0mm setback

    Type: Rigid

    Pedals

    VP VPE-537

    Groupset
    Rear Derailleur

    Shimano Deore M5120, SGS

    Crank

    Shimano CRE70-B, 34 teeth

    Shifters

    Shimano Deore M4100

    Cassette

    Shimano M4100, 11-46 teeth, 10 speed

    Chain

    KMC e10s

    Brakes

    Shimano MT200, 2 piston

    Type: Shimano Hydraulic Disc

    Wheels
    Rims

    MERIDA COMP CC, 20mm inner width, material: aluminium

    Spokes

    Black stainless

    Front Hub

    Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock

    Rear Hub

    Shimano MT400-B, 110x15mm width front hub, 32 spoke holes, Centerlock, 148x12mm width rear hub, 36 spoke holes, Centerlock

    Tires

    Kenda Booster, 29x2.2", wire

    Disc Rotors

    Shimano RT30 / Shimano RTEM300, 180 mm

    Electric Components
    Motor

    Shimano EP8, 85Nm

    Battery

    Simplo Internal Battery, 750Wh

    Display

    Shimano SC-E5003A

    Accessories
    Fenders

    Sunnywheel SW-FA311-65A/ SW-FA311-65E1

    Racks

    MERIDA MA008-1, spring clamp, Spanninga GLOW XE rear light

    Lock

    Abus 5650 LH-3 lock

    Stand

    Massload CL-KA98
