 | Recommended |
|---|
MSRP | ||
|---|---|---|
Where to Buy | — $1 At | |
Category | Crosscountry, E-Bike | |
Fork | Suntour RAIDON | |
Wheels | Aluminum | |
| 27.5″ | ||
Brakes | Mechanical Disc | |
| Shimano 250W 70Nm mid-drive | ||
| Shimano 504Wh | ||
Groupset | XT, SLX | |
Drivetrain | 1 × 11 | |
Suspension | Hardtail | |
Front Travel | 100mm | |
Brand Site | ||
Summary | The Merida eBIG.SEVEN 800 EQ is a 27.5″ hardtail crosscountry e-bike with high-end components and mechanical disc brakes. | |
Based on frame geometry and build specs.
Frame | eBIG.SEVEN | |
|---|---|---|
Fork | Suntour Raidon32 LO-R, Air, 100mm suspension travel, Tapered | |
Headset | MERIDA 2341 Neck, 2191022388 | |
Handlebar | MERIDA Expert CC, 720mm width, 10mm rise | |
Saddle | MERIDA Comfort | |
Seatpost | MERIDA Expert, 30.0mm diameter, 0mm setback | |
Pedals | VP, VPE-537 |
Rear Derailleur | Shimano XT M8000 Shadow+ | |
|---|---|---|
Front Derailleur | no | |
Crank | Shimano CRE80-B, 38 teeth | |
Shifters | no / Shimano SLX 11 | |
Cassette | Shimano M7000, 11-46 teeth, 11 speed | |
Chain | KMC e11 Sport EPT | |
Chain Guide | Mr. Control CH-E8 mini | |
Brakes | Shimano SLX | |
Brake Levers | attached |
Rims | MERIDA Comp CC, 20mm inner width, | |
|---|---|---|
Spokes | Black stainless | |
Front Hub | Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock | |
Rear Hub | Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock | |
Tires | Continental Double Fighter III, 27.5x2.0", wire |
Motor | Shimano E8000, 70Nm | |
|---|---|---|
Battery | Shimano E8010, 504 Wh | |
Display | Shimano SC-E6100 |
Lights | SuperNova E3 E-BIKE V6S / Rear light H-Trace E-Bike | |
|---|---|---|
Fenders | SW-FA 513 w/MSI(SW-FV-513 + FV-515) | |
Racks | YA-355B | |
Bell | Alloy |
