MSRP | $579 | |
---|---|---|
Where to Buy | — $1 At | $579 At Trek |
Category | Crosscountry, E-Bike | Crosscountry |
Weight | 32.2 lbs | |
Aluminum | ||
Fork | Suntour RAIDON (air) | Suntour XCE (coil) |
Wheels | Aluminum | |
29″ | 27.5″ / 29″ | |
Brakes | Mechanical Disc | Mechanical Disc |
Shimano 250W 70Nm mid-drive | ||
Shimano 504Wh | ||
Groupset | XT, SLX | Tourney, Altus |
Drivetrain | 1 × 11 | 2 × 7 |
Suspension | Hardtail | Hardtail |
Front Travel | 100mm | 100mm |
Brand Site | ||
Summary | The Merida eBIG.NINE 800 EQ is a 29″ hardtail crosscountry e-bike with high-end components and mechanical disc brakes. |
Based on frame geometry and build specs.
Frame | eBIG.NINE | Size: XS, S, Alpha Silver Aluminum, curved top tube, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR; Size: M, ML, L, XL, Alpha Silver Aluminum, internal routing, chainstay disc brake mount, rack and kickstand mount, 135x5mm QR |
---|---|---|
Fork | Suntour Raidon32 LO-R, Air, 100mm suspension travel, Tapered Travel: 100mm Spring Type: Coil | Size: XS, SR Suntour XCE 28, coil spring, preload, 42mm offset for 27.5'' wheel, 100mm QR, 80mm travel; Size: S, SR Suntour XCE 28, coil spring, preload, 42mm offset for 27.5'' wheel, 100mm QR, 100mm travel; Size: M, ML, L, XL, SR Suntour XCE 28, coil spring, preload, 46mm offset for 29'' wheel, 100mm QR, 100mm travel Travel: 100mm Spring Type: Coil |
Bottom Bracket | VP BC73, 73mm, threaded cartridge | |
Headset | MERIDA 2341 Neck, 2191022388 | Semi-integrated, 1-1/8'' |
Stem | Size: XS, S, Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 50mm length; Size: M, Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 60mm length; Size: ML, L, Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: XL, Bontrager Comp, 31.8mm, Blendr compatible, 7 degree, 80mm length | |
Handlebar | MERIDA Expert CC, 720mm width, 10mm rise | Size: XS, S, Bontrager alloy, 31.8mm, 5mm rise, 690mm width; Size: M, ML, L, XL, Bontrager alloy, 31.8mm, 15mm rise, 750mm width |
Saddle | MERIDA Comfort | Bontrager Verse Short, stainless steel rails |
Seatpost | MERIDA Expert, 30.0mm diameter, 0mm setback | Size: XS, S, Bontrager alloy, 31.6mm, 12mm offset, 330mm length; Size: M, Bontrager alloy, 31.6mm, 12mm offset, 360mm length; Size: ML, L, XL, Bontrager alloy, 31.6mm, 12mm offset, 400mm length |
Pedals | VP, VPE-537 | VP-536 nylon platform |
Grips | Bontrager XR Endurance Comp, lock-on |
Rear Derailleur | Shimano XT M8000 Shadow+ | Shimano Tourney TY300 |
---|---|---|
Front Derailleur | no | Shimano Altus M315, 34.9mm clamp, top swing, dual pull |
Crank | Shimano CRE80-B, 38 teeth | Size: XS, S, M, ProWheel TM-CY10, 36/22, 170mm length; Size: ML, L, XL, ProWheel TM-CY10, 36/22, 175mm length |
Shifters | no / Shimano SLX 11 | Size: XS, S, M, ML, L, XL, Shimano EF500, 8 speed; Size: XS, S, M, ML, L, XL, Shimano EF500, 7 speed |
Cassette | Shimano M7000, 11-46 teeth, 11 speed | Shimano TZ500, 14-34, 7 speed |
Chain | KMC e11 Sport EPT | KMC Z7, 7 speed |
Chain Guide | Mr. Control CH-E8 mini | |
Brakes | Shimano SLX | Size: XS, S, M, ML, L, XL, Tektro MD-M280 mechanical disc; Size: XS, S, M, ML, L, XL, Tektro MD-M281 mechanical disc |
Brake Levers | attached |
Rims | MERIDA Comp CC, 20mm inner width, | |
---|---|---|
Spokes | Black stainless | |
Front Hub | Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock | |
Rear Hub | Shimano Deore, 110x15mm width, 32 spoke holes, Centerlock / Shimano Deore, 148x12mm width, 36 spoke holes, Centerlock | |
Tires | Continental Double Fighter III, 29x2.0", wire | |
Disc Rotors | Tektro, 6-bolt, 160mm |
Motor | Shimano E8000, 70Nm | |
---|---|---|
Battery | Shimano E8010, 504 Wh | |
Display | Shimano SC-E6100 |
Lights | SuperNova E3 E-BIKE V6S / Rear light H-Trace E-Bike | |
---|---|---|
Fenders | SW-FA 513 w/MSI(SW-FV-513 + FV-515) | |
Racks | YA-355B | |
Bell | Alloy |
