MSRP | ||
|---|---|---|
Where to Buy | — $1 At | |
Category | Trail | |
Frame | Aluminum | |
| RockShox Judy | ||
Wheels | Aluminum | |
Wheel Size | 27.5″ | |
| Shimano Hydraulic Disc | ||
| CUES | ||
Drivetrain | 1 × 9 | |
Suspension | Hardtail | |
Front Travel | 120mm | |
Brand Site | ||
Summary | The Merida BIG.SEVEN 80 is a 27.5″ aluminum frame hardtail trail bike with upper mid-range components. | |
Ask 99 Spokes
Based on frame geometry and build specs.
Frame | BIG.SEVEN TFS V, material: aluminum, 27.5 wheelsize, 135x9mm axle standard, BSA bottom bracket standard, Smooth welding BB Standard: BSA, 73mm, Threaded | |
|---|---|---|
Fork | Rock Shox Judy TK, Coil, 120mm suspension travel Lockout, 42mm fork offset, 27.5x2.25" max. wheelsize Travel: 120mm Spring Type: Coil | |
Bottom Bracket | Shimano UN101 LL123 | |
Headset | FSA NO.55R/57SC/57B | |
Handlebar | MERIDA CC, material: aluminium, 15mm rise, XXS/XS: 700WHB, S: 720mm width | |
Saddle | MERIDA COMP SL | |
Seatpost | MERIDA COMP CC, material: aluminium, 30.9mm diameter, 0mm setback Type: Rigid | |
Pedals | VP VPE 536 |
Rear Derailleur | Shimano Cues U4000, GS | |
|---|---|---|
Crank | Shimano Cues UT400-1, 32 teeth, MAT Aluminium, 165mm on all sizes | |
Shifters | Shimano Cues U4000 | |
Cassette | SunRace U9 CS-U980 9AZ, 11-46 teeth, 9 speed | |
Chain | KMC xGlide | |
Brakes | Shimano MT200, hydraulic brake Type: Shimano Hydraulic Disc |
Rims | MERIDA COMP CC II, 25mm inner width, material: aluminium, tubeless ready | |
|---|---|---|
Spokes | Black steel | |
Front Hub | Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock | |
Rear Hub | Shimano TX505, 100x9mm width front hub, 32 spoke holes, Centerlock, 135x9mm width rear hub, 32 spoke holes, Centerlock | |
Tires | Kenda Booster, 27.5x2.4" | |
Disc Rotors | Shimano RT10, 160 mm |
