    BIG.NINE 202024 Merida
    Recommended
    MSRP
    ($634)
    Where to Buy
    —
    $1

    At

    Category
    		Crosscountry
    Weight
    		32.6 lbs
    Frame
    		Aluminum
    		Suntour XCT
    Wheels
    		Aluminum
    Wheel Size
    		29″
    		Tektro Hydraulic Disc
    		Shimano
    Drivetrain
    		2 × 8
    Suspension
    		Full
    Front Travel
    		100mm
    Rear Travel
    		100mm
    Brand Site

    merida-bikes.com

    Summary
    		The Merida BIG.NINE 20 is a 29″ aluminum frame full suspension crosscountry bike with modest components.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from a Gear Advisor at Jenson USA

    Text a Gear Advisor
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    BIG.NINE 20
    Other Crosscountry bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    28 mph

    BIG.NINE 20

    Highest gear

    (descending)

    Geometry
    Specs
    BIG.NINE 202024 Merida
    Frame

    BIG.NINE TFS IV, 100 mm suspension travel, material: aluminum, 29x2.25" max. wheelsize, 135x9 mm axle standard, BSA bottom bracket standard

    BB Standard: BSA, 100mm, Threaded

    Fork

    SR Suntour XCT30 HLO, Coil, 100 mm suspension travel, lockout, max. 29x2,25" wheelsize

    Travel: 100mm

    Spring Type: Coil

    Bottom Bracket

    BSA, 100mm, threaded

    Headset

    MERIDA M2345

    Handlebar

    MERIDA CC, material: aluminium, 690 mm width, 15 mm rise

    Saddle

    MERIDA Sport comfort

    Seatpost

    MERIDA CC, 30.9 mm diameter, 15 mm setback, material: aluminium

    Type: Rigid

    Pedals

    VP VPE-891

    Groupset
    Rear Derailleur

    Shimano RD-M380-8, SGS

    Front Derailleur

    Shimano FD-M315-TS

    Crank

    Shimano FC-M315-2, 36-22 teeth, MAT Aluminium, 170 mm-S, 175 mm-M up

    Shifters

    Shimano ST-EF505

    Cassette

    Sunrace CSM558AU, 11-32 teeth, 8 speed

    Chain

    KMC Z8.3

    Brakes

    Tektro M275, hydraulic brake

    Type: Tektro Hydraulic Disc

    Wheels
    Rims

    MERIDA CC, 17 mm inner width, material: aluminium

    Spokes

    Black steel

    Front Hub

    Shimano TX505, 100x9 mm width front hub, 32 spoke holes, Centerlock

    Rear Hub

    Shimano TX505, 135x9 mm width rear hub, 32 spoke holes, Centerlock

    Tires

    MERIDA K1080, 29x2.2", wire

    Disc Rotors

    Shimano RT10, 160 mm
