    XC 242018 KHS
    Recommended
    MSRP
    $1,599
    Where to Buy
    —
    $1

    At

    Category
    		Mountain Youth
    3.7
    Frame
    		Aluminum
    		RST
    Wheels
    		Aluminum
    Wheel Size
    		24″
    		Tektro Hydraulic Disc
    		NX
    Drivetrain
    		1 × 11
    Suspension
    		Full
    Front Travel
    		100mm
    Rear Travel
    		100mm
    Brand Site
    Summary
    		The KHS XC 24 is a 24″ aluminum frame mountain youth bike with upper mid-range components and tektro hydraulic disc brakes.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from a Gear Advisor at Jenson USA

    Text a Gear Advisor
    Similar Bikes
    Insights
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    21 mph

    XC 24

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    XC 242018 KHS
    Frame

    24" Alloy 6061, Horst Bearing Linkage, 100mm Travel, w/ Replaceable Der Hanger

    Color: Gray / Black

    Fork

    RST First 26 Air, 100mm, Alloy Steerer, Magnesium lowers, Hydraulic Damp, External rebound, Lockout

    Travel: 100mm

    Spring Type: Air

    Shock

    X-Fusion 02 Pro R, Air, Ext Rebound

    Travel: 100mm

    Bottom Bracket

    Cartridge Bearing

    Headset

    FSA Threadless 1-1/8, Zero Stack

    Stem

    3D Forged Alloy 4-bolt, 40mm

    Handlebar

    Alloy Riser, 31.8, 720X12mm, Butted

    Saddle

    KHS Junior ATB

    Seatpost

    Alloy Micro Adjust, 30.9 x 300mm

    Type: Rigid

    Pedals

    N/A

    Grips

    Q2 Lock-on

    Groupset
    Rear Derailleur

    SRAM NX 1, 11s X-Horizon, Type 3

    Front Derailleur

    N/A

    Crank

    KHS 2pc Forged W/Outboard Bearing, 32T, 155mm

    Shifters

    SRAM NX 1, 11s Trigger, Right Only

    Cassette

    SunRace, 11-42T, 11-speed

    Chain

    SRAM PC-1110

    Brakes

    Tektro HD-M286, Hydraulic Disc, 160mm Rotors

    Type: Tektro Hydraulic Disc

    Brake Levers

    Tektro HD-M286 Short Reach

    Wheels
    Rims

    Alloy, Doublewall, 24x32H

    Spokes

    14G Black w/Alloy Nipples, 32X32

    Tires

    Maxxis Snyper, 24 x 2.0, 60 TPI Folding
