MSRP | $1,649 | $2,499 |
---|---|---|
Where to Buy | — $1 At | |
Category | Gravel | Gravel |
Weight | 24.3 lbs | 21.5 lbs |
Steel | Aluminum | |
Fork | Carbon | Carbon |
Wheels | Aluminum | Aluminum |
Wheel Size | 700c | 700c |
Clearance | 45c | |
Brakes | Hydraulic Disc | Hydraulic Disc |
Groupset | GRX 400, FSA | GRX 800, GRX 600 |
Drivetrain | 2 × 10 | 2 × 11 |
Brand Site | ||
Summary | The Jamis RENEGADE S3 is a steel frame gravel bike with mid-range components and hydraulic disc brakes. |
Based on frame geometry and build specs.
Frame | UPDATED Jamis Size Specific Design frame geometry, Reynolds 520 double-butted chromoly main tubes, 44mm head tube for tapered fork, threaded BB shell, 12mm Thru-axle, 163x1.5x14, flat mount chain stay disc brake mounts, top tube mounted full cable housing, 3 waterbottle mounts, rack and fender eyelets. BB Standard: BSA, 68mm, Threaded | 300 Series Alpha Aluminum, tapered head tube, Internal cable routing, 3S chain keeper, T47 BB, rack and fender mounts, integrated frame bag mounts, flat mount disc, 142x12mm thru axle BB Standard: BSA, 68mm, Threaded |
---|---|---|
Fork | Jamis Adventure ECO monocoque carbon composite, 12mm Jamis MTS (Modular Thru-axle System), 118x1.5x13, with stainless interface and carbon dropouts, tapered steerer with 1.5” hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and water bottle eyelets | Checkpoint, full carbon, tapered carbon steerer, rack mounts, fender mounts, flat mount disc, 12x100mm thru axle |
Bottom Bracket | FSA BB-4000 MegaExo | Praxis, T47 threaded, internal bearing |
Headset | FSA Orbit ITA B Internal/External, 1.5 - 1 1/8” | |
Stem | Ritchey 4-Axis 3D forged 6061 alloy, 6˚ x 60mm (44), 70mm (48/51), 80mm (54/56), 100mm (58/61) | Size: 49, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: 52, 54, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 56, 58, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 61, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length |
Handlebar | Ritchey Baquiano Comp, 6061 aluminum, 73 reach, 118 ergonomic drop with 12° flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61) | Size: 49, Bontrager Elite Gravel, 38cm width; Size: 52, Bontrager Elite Gravel, 40cm width; Size: 54, 56, Bontrager Elite Gravel, 42cm width; Size: 58, 61, Bontrager Elite Gravel, 44cm width |
Saddle | Selle Royal Asphalt with integrated clip system | Size: 49, 52, Bontrager Verse Comp, steel rails, 155mm width; Size: 54, 56, 58, 61, Bontrager Verse Comp, steel rails, 145mm width |
Seatpost | Ritchey Road, 27.2 x 300mm with cromo seat pin | Bontrager alloy, 27.2mm, 12mm offset, 330mm length |
Pedals | N/A |
Rear Derailleur | Shimano GRX RD-RX400 Shadow Plus | Shimano GRX RX810, long cage, 34T max cog |
---|---|---|
Front Derailleur | GRX FD-RX400 | Shimano GRX RX810, braze-on |
Crank | FSA OMEGA Modular DM MegaExo, 46/30T, 165mm (44/48), 170mm (51) 172.5mm (54/56) 175mm (58/61) | Size: 49, Shimano GRX RX600, 46/30, 165mm length; Size: 52, Shimano GRX RX600, 46/30, 170mm length; Size: 54, 56, Shimano GRX RX600, 46/30, 172.5mm length; Size: 58, 61, Shimano GRX RX600, 46/30, 175mm length |
Shifters | Shimano GRX ST-RX400 Dual Control STI, 20-speed | Shimano GRX RX600, 11 speed |
Cassette | Shimano 10-speed, 11-36T | Shimano 105 HG700-11, 11-34, 11 speed |
Chain | KMC 10-speed X10 | Shimano HG601, 11 speed |
Brakes | Shimano GRX BR-RX400 flat mount hydraulic disc brakes with resin pads, Shimano 160mm rotors with GRX ST-RX400 Dual Control STI levers | Shimano RX400 hydraulic disc, flat mount |
Rims | WTB ST i23 TCS 2.0 (UST Tubeless Compliant System) disc rims, 32H, Joytec alloy 6-bolt hubs, 14g stainless steel spokes and front 12mm/rear 12x142 thru-axle with Switch Lever | Size: 49, 52, 54, 56, 58, 61, Bontrager Paradigm, Tubeless Ready, 24-hole, 21mm width, Presta valve; Size: 49, 52, 54, 56, 58, 61, Bontrager Paradigm SL, Tubeless Ready, 24-hole, 21mm width, Presta valve |
---|---|---|
Spokes | 14g stainless steel, black | |
Front Hub | Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle | |
Rear Hub | Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle | |
Tires | Donnelly X Plor MSO, 650 x 36c (44-48) 700 x 36c (51-61), 30TPI with protection belt | Bontrager GR1 Team Issue, Tubeless Ready, Inner Strength casing, aramid bead, 120 tpi, 700x40mm |
Disc Rotors | Shimano RT70, centerlock, 160mm |
