Bike Comparison
    RENEGADE EXPLORE2019 Jamis
    Recommended
    MSRP
    $1,079
    Where to Buy
    —
    $1

    At

    Category
    		Gravel
    Weight
    		23.0 lbs
    2.5
    Frame
    		Aluminum
    Fork
    		Carbon
    Wheels
    		Aluminum
    Wheel Size
    		700c
    Clearance
    		42c (700c) / 47c (27.5″)
    Brakes
    		Mechanical Disc
    Motor
    Battery
    Groupset
    		Sora, FSA
    Drivetrain
    		2 × 9
    Brand Site

    jamisbikes.com

    Summary
    		The Jamis RENEGADE EXPLORE is an aluminum frame gravel bike with mid-range components and mechanical disc brakes.
    Similar Bikes
    Accessories
    Ride Feel

    Based on frame geometry and build specs.

    Rider Position
    relaxedaggressive
    RENEGADE EXPLORE
    Other Gravel bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    39 mph

    RENEGADE EXPLORE

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    RENEGADE EXPLORE2019 Jamis
    Frame

    Jamis Size Specific Design frame geometry, 6061 aluminum double-butted SST main frame, top tube mounted full cable housing, 1.5 - 1 1/8” tapered head tube, 31.8mm seat tube for 27.2 seat post, seat stay disc brake mounts, replaceable derailleur hanger, 3 waterbottle mounts, rack and fender eyelets, clearance for 700x42c and 650x47c tires.

    Tire Clearance: 42c (700c) / 47c (27.5″)

    Fork

    Jamis Adventure ECO monocoque carbon composite, 12mm Jamis MTS (Modular Thru-axle System) with stainless interface and carbon dropouts, tapered steerer with 1.5” hollow formed crown, flat mount disc brakes with internal cable routing, exposed fender, lowrider and water bottle eyelets

    Bottom Bracket

    FSA sealed cartridge, 68 x 110.5mm

    Headset

    FSA Orbit C-40B Internal/External, 1.5 - 1 1/8”

    Stem

    Ritchey 4-Axis 3D forged 6061 alloy, 6˚ x 70mm (44), 80mm (48/51), 90mm (54/56), 110mm (58/61)

    Handlebar

    Ritchey Evomax Comp, 6061 aluminum, 73 reach, 120 drop with 12° flare, 31.8 x 400 (44) 420 (48-51) 440mm (54-56), 460mm (56-61)

    Saddle

    Selle Royal Asphalt with integrated clip system

    Seatpost

    Jamis Road, micro-adjust, 27.2 x 350mm cromo seat pin

    Pedals

    N/A

    Groupset
    Rear Derailleur

    Shimano Sora RD-R3000 GS

    Front Derailleur

    Sora FD-R3000

    Crank

    FSA Vero, 50/34T, 165mm (44/48), 170mm (51) 172.5mm (54/56) 175mm (58/61)

    Shifters

    Shimano Sora ST-R3000 Dual Control STI, 18-speed

    Cassette

    Shimano HG400 9-speed, 11-34T

    Chain

    KMC Z9

    Brakes

    Tektro Lyra mechanical cable actuated disc brake with 160mm wave rotors and Shimano Sora ST-R3000 levers

    Wheels
    Rims

    WTB ST i23 TCS 2.0 (UST Tubeless Compliant System) disc rims, 32H, Formula 12mm front and QR rear alloy 6-bolt hubs and 14g stainless steel spokes

    Tires

    Donnelly X Plor MSO, 650 x 36c (44-48) 700 x 36c (51-61), 30TPI with protection belt
