    Hatch 22024 Diamondback
    Recommended
    MSRP
    $725
    Where to Buy
    —
    $1

    At

    Category
    		Crosscountry
    3.2
    Frame
    		Aluminum
    		Suntour XCE
    Wheels
    		Aluminum
    Wheel Size
    		27.5″
    		Hydraulic Disc
    		Tourney
    Drivetrain
    		3 × 7
    Suspension
    		Hardtail
    Front Travel
    		100mm
    Brand Site

    diamondback.com

    Summary
    		The Diamondback Hatch 2 is a 27.5″ aluminum frame hardtail crosscountry bike with mid-range components.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from a Gear Advisor at Jenson USA

    Text a Gear Advisor
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    Hatch 2
    Other Crosscountry bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    25 mph

    Hatch 2

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    Hatch 22024 Diamondback
    Frame

    Custom Formed AL-6061 Heat Treated Aluminum with Progressive wheel Sizing (27.5" - XS,S) (29" - M,L,XL)

    BB Standard: BSA, 73mm, Threaded

    Fork

    SR Suntour XCE-28 100mm of Travel with Pre-Load Adjuster, IS Disc mounts

    Travel: 100mm

    Spring Type: Coil

    Shock

    N/A

    Bottom Bracket

    BSA, Sealed Cartridge Bearing

    Headset

    1-1/8 Semi Integrated,Cartridge Bearing

    Stem

    Aluminum MTB 31.8 Bar Bore Stem

    Handlebar

    Aluminum 31.8mm Bar, 25mm Rise

    Saddle

    MTB Saddle

    Seatpost

    Aluminum 27.2 Post with 15mm Offset

    Type: Rigid

    Pedals

    Wellgo Plastic Body Platform

    Grips

    MTB Grip

    Groupset
    Rear Derailleur

    Shimano Tourney TY300

    Front Derailleur

    Shimano Tourney TY500, Dual Pull

    Crank

    Shimano Tourney TY301, 42/34/24t

    Shifters

    Shimano SL-M315 3x7 Speed, Rapid Fire Shifter

    Cassette

    Shimano MFTZ500 14-28 Tooth Freewheel

    Chain

    KMX Z-7

    Brakes

    Radius BH860 Hydraulic Disc, 160mm Front / 160mm Rear

    Type: Hydraulic Disc

    Brake Levers

    Radius BH860 Hydraulic Levers with Micro Adjust

    Wheels
    Rims

    Aluminum MTB DDM-2 Double Wall, 32 hole

    Spokes

    Steel J-Bend

    Front Hub

    Formula DC-19 Aluminum 6 bolt Disc, Quick Release

    Rear Hub

    Formula DC-31, Aluminum 6 bolt Disc, Quick Release

    Tires

    Vee Tire Rail Escape, 27.5x2.25" or 29x2.25"
