Bike Comparison
    MTR 8.62025 Boardman
    Recommended
    MSRP
    ($1,749)
    Where to Buy
    —
    $1

    At

    Category
    		Trail
    Weight
    		35.3 lbs
    4.0
    Frame
    		Aluminum
    		Suntour XCR
    Wheels
    		Aluminum
    Wheel Size
    		29″
    		Tektro HD Hydraulic Disc
    		microSHIFT Advent X
    Drivetrain
    		1 × 10
    Suspension
    		Full
    Front Travel
    		130mm
    Rear Travel
    		130mm
    Brand Site

    boardmanbikes.com

    Summary
    		The Boardman MTR 8.6 is a 29″ aluminum frame full suspension trail bike with upper mid-range components.

    Ask 99 Spokes

    Want to ask an actual human?

    Get free advice from a Gear Advisor at Jenson USA

    Text a Gear Advisor
    Similar Bikes
    Insights
    Ride Feel

    Based on frame geometry and build specs.

    Terrain
    easyextreme
    Handling
    nimblestable
    MTR 8.6
    Other Trail bikes
    Gear Range

    A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

    Lowest gear

    (climbing)

    25 mph

    MTR 8.6

    Highest gear

    (descending)

    Spec Level

    Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

    Geometry
    Specs
    MTR 8.62025 Boardman
    Frame

    6061 Alloy with 130mm RockShox Deluxe Select

    Hanger Standard: UDH

    Fork

    Suntour XCR34-Boost, 130mm

    Travel: 130mm

    Bottom Bracket

    Prowheel, square taper, sealed cartridge, 113mm

    Headset

    FSA No.42,ACB-A

    Stem

    Boardman Alloy, 45mm

    Handlebar

    Boardman Alloy - 31.8 SM 740, MD/LG/XL 760mm 15mm Rise

    Saddle

    Boardman MTB

    Seatpost

    Boardman Alloy, 31.6 SM/MD 350mm, LG/XL 400mm

    Type: Rigid

    Pedals

    Wellgo flats, 9/16”

    Groupset
    Rear Derailleur

    microSHIFT ADVENT RD-M6205GM-B, with clutch

    Crank

    Prowheel Charm, 32T

    Shifters

    microSHIFT ADVENT, SL-M9605-R -10 speed

    Cassette

    microSHIFT CS-H104, 10 Speed, 11-48T

    Chain

    KMC X10, 10 Speed

    Brakes

    Tektro HD-280 Hydraulic, 180mm Rotot

    Type: Tektro HD Hydraulic Disc

    Wheels
    Rims

    Boardman MTB Alloy

    Tires

    Front - Maxxis Rekon 29"x2.4", Rear - Maxxis Forekaster 29"x2.4"
