Today’s Deals2025 Winora
Sinus iX10
A 650b aluminum frame commuter e-bike with upper mid-range components and shimano hydraulic disc brakes.
Compare the full range
Manufacturer Price
€3,399($3,953)| Weight | 54.7 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail |
| Fork | Suntour NEX |
| Wheels | 650b Aluminum |
| Drivetrain | 1 × 10 |
| Groupset | Deore |
| Motor | Bosch 600W 85Nm mid-drive |
| Battery | Bosch 500Wh |
| Brakes | Shimano Hydraulic Disc |
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full SINUS model range
View Comparison5'2" – 5'8"
5'6" – 5'11"
5'9" – 6'1"
6'0" – 6'5"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | High Aluminium Gents |
|---|---|
| Fork | Suntour NEX E25-HLO Spring Type: Coil |
| Bottom Bracket | integrated in the motor |
| Headset | Feimin A-Head Tapered |
| Stem | Adjustable Alu, winkelverstellbar |
| Handlebar | Ergoriser, oversize |
| Saddle | Selle Royal Viento |
| Seatpost | Non Suspension Type: Suspension |
| Pedals | VP E461 |
| Rear Derailleur | Shimano Deore M6000 |
|---|---|
| Shifters | Shimano Deore M6000 |
| Cassette | Shimano HG500 |
| Chain | KMC Chain e10S |
| Brakes | Shimano Hydraulic Disc brake MT400 Type: Shimano Hydraulic Disc |
| Brake Levers | Shimano MT401-3 |
| Rims | Ryde Hollow rim Zac421 |
|---|---|
| Front Hub | alu hub |
| Rear Hub | alu hub |
| Tires | Schwalbe Marathon Almotion 55-584 |
| Motor | Bosch Performance Line CX Performance CX GEN4 |
|---|---|
| Battery | Bosch Li-ION, Capacity: 500 Wh, Location: Powertube |
| Display | Bosch Purion Purion |
| Charger | Bosch quick charger 4A |
| Lights | Front: Herrmans H-Black MR4, Rear: Busch & Müller Shine Evo, integrated in the luggage carrier |
|---|---|
| Fenders | EuroFender Winora schwarz matt |
| Racks | Racktime RT-336 |
| Lock | Abus Ring lock upgradable over Plus System |
