2024 Winora
Yakun tour
A 650b aluminum frame hybrid e-bike with upper mid-range components and hydraulic disc brakes.
Compare the full range
Manufacturer Price
€3,599($3,954)| Weight | 53.1 lbs |
|---|---|
| Frame | Aluminum |
| Suspension | Hardtail, 60mm |
| Fork | Suntour NCX |
| Wheels | 650b Aluminum |
| Groupset | XT, Deore |
| Motor | Yamaha mid-drive |
| Battery | Yamaha 500Wh |
| Brakes | Hydraulic Disc |
For This Bike
Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.
Compare the full Yakun model range
View Comparison5'2" – 5'7"
5'5" – 5'10"
5'8" – 6'2"
6'0" – 6'5"
None yet.
Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.
| Frame | High Aluminium Gents Color: Gunmetal / Black |
|---|---|
| Fork | Suntour Suspension NCX E45-LOR Travel: 60mm Spring Type: Coil |
| Bottom Bracket | integrated in the motor |
| Headset | Feimin A-Head Tapered |
| Stem | Alu |
| Handlebar | Ergoriser, oversize |
| Saddle | Winora Yukon, embossed |
| Seatpost | BySchulz Suspension Type: Suspension |
| Pedals | VP 469 |
| Grips | retro stitched |
| Rear Derailleur | Shimano Deore XT T8000 |
|---|---|
| Front Derailleur | Shimano Deore XT T781 |
| Crank | FSA, Aluminium, 48 teeth |
| Shifters | Shimano Deore M6000 |
| Cassette | Shimano HG50 |
| Chain | KMC Chain e10S |
| Brakes | Magura Hydraulic Disc brake MT4 Type: Hydraulic Disc |
| Brake Levers | Magura MT4 |
| Rims | Rodi Hollow rim Black Rock 23 |
|---|---|
| Spokes | Stainless spokes, black |
| Front Hub | alu disc thru-axle 15x100 |
| Rear Hub | aluminium disc thru-axle 12x142 |
| Tires | Schwalbe Marathon Almotion 55-584 |
| Motor | Yamaha PW-X Series |
|---|---|
| Battery | Yamaha Li-ION, Capacity: 500 Wh, Location: Downtube |
| Display | Yamaha |
| Charger | Yamaha quick charger 4A |
| Lights | Front: Busch & Müller Lumotec IQ-X E, Rear: LED mini |
|---|---|
| Fenders | double wall |
| Racks | Winora |
Last updated June 17
