2024 Winora

YAKUN R5

A 650b aluminum frame commuter e-bike with high-end components and shimano hydraulic disc brakes.
Compare the full range

Manufacturer Price

€4,499($5,211)
Weight64.3 lbs
FrameAluminum
SuspensionHardtail, 80mm
ForkSuntour X1
Wheels650b Aluminum
DrivetrainBelt Drive, Internally Geared Hub
GroupsetGates CDX, Nexus
MotorBosch hub-drive
BatteryBosch 600Wh
BrakesShimano Hydraulic Disc
SeatpostDropper
View on winora.comLearn about Winora
Add to Comparison
Shop with an Expert at Upway
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Compare the full Yakun model range

View Comparison
Specs
Build
Frame

High Aluminium Uni

Fork

Suntour SF23 X1 Boost LO-R 80 mm

Travel: 80mm

Spring Type: Coil

Headset

Glory Wheel Semi-integrated ICR-51.9 ZS56/38

Stem

Satori Adjustable TDS-673 Dia. 31.8mm, L: 90 mm

Handlebar

JD TR28AL, Dia. 31.8 mm, Rise: 19 mm

Saddle

Selle Royal Vivo Ergo 1217 HRN

Seatpost

Limotec Dropperpost Alpha A1, Dia. 34.9 mm, Travel: 125 mm

Type: Dropper

Pedals

VP VPE-625 MTB Pedal w. Reflector

Groupset
Crank

XLC Kies ISIS Cranks + GATES CDX Chainring + Spider

Shifters

Shimano Gripshift Nexus SL-C7000-5R, Gripshift

Cassette

Gates Carbon Drive CDX Sprocket, 5 Spline

Chain

Gates Belt Carbon Drive Belt CDX, 125T

Chain Guide

Winora Belt Guard

Brakes

Shimano Hydraulic Disc brake

Type: Shimano Hydraulic Disc

Wheels
Rims

Schurmann YAK Disc 25-584, 32H, 8,5 mm Valve

Front Hub

Shimano HB-TC500-15-B 15x110 mm, 32H, CL

Rear Hub

Shimano Nexus SG-C7000-5D, 32H, CL, Internal Geared Hub

Tires

Schwalbe AL Grounder Performance 60-584

Electric Components
Motor

Bosch

Battery

Bosch Li-ION InTube 600Wh, Capacity: 600 Wh, Location: Powertube

Display

Bosch Kiox 300 + LED Remote

Charger

Bosch Charger 4A 230V

Accessories
Lights

Front: Trelock Skybeamer 300, 6-24V, Rear: Spanninga Pimento XE with Brakelight, 6-36 V

Fenders

Curana Apollo 65 Aluminium extra matte black

Racks

Easylife System luggage carrier
