Shimano BB-ES300 Splined Hollow-Type, 68mm

TRP HyRd Hydraulic, 160mm Rotor, Flat Mount, Linear Outer Cables with Kevlar Reinforcement, Internal Routing

Shimano FC-R345, Double 50-34, 52 170mm, 54/56/58 175mm 9 Speed

Whyte Straight Bladed Carbon Fork, Tapered Alloy Steerer, Internal Cable Routing, Flat Mount Dropouts with Eyelets for Mudguards

6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Internal Cable Routing with BBX and Flat Mount 160 Chainstay Disc Mount

Alloy, Double Sealed Cartridge Bearings, Centre-Lock, 28 Hole

Whyte Anti Slip Comfort with 3M Reflective Logos

Whyte 6061 Alloy, Road, 31.8mm, Compact "Wing" Bar, 50cm 380mm, 52/54cm 400mm, 56cm 420mm, 58cm 440mm

FSA No. 42, Integrated Road, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings

Alloy, Double Sealed Cartridge Bearings, Centre-Lock, 32 Hole

Whyte Disc Road, Low Profile, 21mm Wide, Tubeless Compatible, 3M Reflective Decals, 32 Hole Rear and 28 Hole Front

Whyte 6061 Alloy, 1pcs 3D Forged, 20mm Offset, 27.2mm x 350mm, 2 Bolt Clamp

2.0mm, PG, Black Stainless, Brass Nipples

Whyte Alloy Road -6° Rise, 50cm 90mm, 52cm 100mm, 54/56cm 110mm, 58cm 120mm Extension

Schwalbe G-One Speed 700 x 30c, Race Guard

The Dorset features Shimano's 9-speed Sora groupset, with a wide-ratio cassette to make getting up the hills a breeze. On the descents, reliable TRP Flat Mount disc brakes will slow you down safely and easily. Whether you're commuting longer distances, winter training or entering summer sportifs, the Whyte Road Disc range offers Cyclo Cross durability with pure Road geometry. A strong alloy 6061 frame, with mudguard and rack eyelets, combined with wide section Offset Rimmed RD-7 rims and TRP Hydro/Mechanical disc brakes will give years of reliable all-season performance.
[split]
REVIEWS
DORSET"If you want a bike for getting from A to B quickly all year round, and that can cope with whatever the British roads and weather can throw at it this could be for you" road.cc (14 of the best 2018 & 2019 road bikes under £1,000)LINKOctober 2018
SPECIFICATION
COLOUR
Matt Granite with Bronze/Dark Red
CASSETTE
Shimano CS-HG-200, 11-32, 9 Speed
FRAME
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Internal Cable Routing with BBX and Flat Mount 160 Chainstay Disc Mount
CHAIN
KMC, 9 Speed
FORK
Whyte Straight Bladed Carbon Fork, Tapered Alloy Steerer, Internal Cable Routing, Flat Mount Dropouts with Eyelets for Mudguards
CRANKSET
Shimano FC-R345, Double 50-34, 52 170mm, 54/56/58 175mm 9 Speed
REAR SHOCK
N/A
BOTTOM BRACKET
Shimano BB-ES300 Splined Hollow-Type, 68mm
HEADSET
FSA No. 42, Integrated Road, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
SEATPOST
Whyte 6061 Alloy, 1pcs 3D Forged, 20mm Offset, 27.2mm x 350mm, 2 Bolt Clamp
REAR HUB
Alloy, Double Sealed Cartridge Bearings, Centre-Lock, 32 Hole
SADDLE
Whyte Custom, Triple Panel Design
FRONT HUB
Alloy, Double Sealed Cartridge Bearings, Centre-Lock, 28 Hole
HANDLEBAR
Whyte 6061 Alloy, Road, 31.8mm, Compact "Wing" Bar, 50cm 380mm, 52/54cm 400mm, 56cm 420mm, 58cm 440mm
SPOKES
2.0mm, PG, Black Stainless, Brass Nipples
STEM
Whyte Alloy Road -6° Rise, 50cm 90mm, 52cm 100mm, 54/56cm 110mm, 58cm 120mm Extension
RIMS
Whyte Disc Road, Low Profile, 21mm Wide, Tubeless Compatible, 3M Reflective Decals, 32 Hole Rear and 28 Hole Front
GRIPS
Whyte Anti Slip Comfort with 3M Reflective Logos
TYRE
Schwalbe G-One Speed 700 x 30c, Race Guard
BRAKES FRONT
TRP HyRd Hydraulic, 160mm Rotor, Flat Mount, Linear Outer Cables with Kevlar Reinforcement, Internal Routing
SHIFT LEVERS
Shimano Sora SL-R3000, 9 Speed
BRAKES REAR
TRP HyRd Hydraulic, 160mm Rotor, Flat Mount, Linear Outer Cables with Kevlar Reinforcement, Internal Routing
FRONT MECH
Shimano Sora FD-R3000
BRAKE LEVERS
Shimano Sora ST-R3000
REAR MECH
Shimano Sora RD-R3000-GS, 9 Speed
PEDALS
Fibre Reinforced Composite Platform
WEIGHT
10.5
Every effort has been made to ensure accuracy throughout this website. However, we do respectfully reserve the right to correct any errors, inaccuracies or omissions and to change or update bike specifications, features, prices and colours without prior notice
Click or scan the QR code for additional specification & replacement parts list.
SIZE GUIDE
52
54
56
58
5’5″ – 5’8″
5’8″ – 5’11″
5’11″ – 6’2"
6’2″ – 6’5
165 – 172 cm
172 – 180 cm
180 – 188 cm
188 – 195 cm
GEOMETRY
SIZE
52cm
54cm
56cm
58cm
A HEAD TUBE ANGLE
72.5
73
73
73
B SEAT TUBE ANGLE
74
73.5
73
73
C TOP TUBE HORIZONTAL
540
555
570
585
D BB HEIGHT ABOVE GROUND
271.5
271.5
271.5
271.5
E STAND OVER HEIGHT
781.5
798.5
814.5
830.5
F WHEEL BASE
998.4
1003.3
1012.8
1027.8
G CHAIN STAY LENGTH
425
425
425
425
H SEAT POST DIAMETER
27.2
27.2
27.2
27.2
I HEAD TUBE LENGTH
145
160
175
190
J SEAT TUBE LENGTH
520
540
560
580
STACK
567.3
583.4
597.7
612.1
REACH
377.3
382.2
387.3
397.9

Whyte DORSET v1

52cm

54cm

56cm

58cm

An aluminum frame endurance bike with mid-range components and trp hy/rd hydraulic disc brakes.

Weight	23.1 lbs
Frame	Aluminum
Fork	Carbon
Wheels	700c Aluminum
Drivetrain	2 × 9
Groupset	Sora
Brakes	TRP HY/RD Hydraulic Disc

Rear Derailleur	Shimano Sora RD-R3000-GS, 9 Speed
Front Derailleur	Shimano Sora FD-R3000
Crank	Shimano FC-R345, Double 50-34, 52 170mm, 54/56/58 175mm 9 Speed
Shifters	Shimano Sora SL-R3000, 9 Speed
Cassette	Shimano CS-HG-200, 11-32, 9 Speed
Chain	KMC, 9 Speed
Brakes	TRP HyRd Hydraulic, 160mm Rotor, Flat Mount, Linear Outer Cables with Kevlar Reinforcement, Internal Routing Type: TRP HY/RD Hydraulic Disc
Brake Levers	Shimano Sora ST-R3000

Rims	Whyte Disc Road, Low Profile, 21mm Wide, Tubeless Compatible, 3M Reflective Decals, 32 Hole Rear and 28 Hole Front
Spokes	2.0mm, PG, Black Stainless, Brass Nipples
Front Hub	Alloy, Double Sealed Cartridge Bearings, Centre-Lock, 28 Hole
Rear Hub	Alloy, Double Sealed Cartridge Bearings, Centre-Lock, 32 Hole
Tires	Schwalbe G-One Speed 700 x 30c, Race Guard
