2025 Voodoo

WAZOO

A 27.5″ aluminum frame hardtail trail bike with mid-range components.

Manufacturer Price

$816
FrameAluminum
SuspensionHardtail, 130mm
ForkSuntour XCM
Wheels27.5″ Aluminum
Drivetrain2 × 9
GroupsetAlivio, Acera
BrakesHydraulic Disc
View on voodoocycles.comLearn about Voodoo
Add to Comparison
Shop with a Gear Advisor
Where to Buy
Similar Bikes
Top Comparison

View more similar bikes →

Insights
Gearing

A bike with lower gearing will be easier to ride up steep hills, while a higher top end means it will pedal faster down hills.

Lowest gear

(climbing)

27 mph

WAZOO

26 mph

Similar Bikes

Highest gear

(descending)

Spec Level

Based on build material and quality level of the frame, fork, wheelset, groupset, suspension system, and more.

Sizing
SM

5'4" – 5'9"

MD

5'7" – 5'11"

LG

5'10" – 6'1"

Rider Fit Notes

None yet.

Do you have this bike? Help other riders make a decision about which size will work for them by sharing your own size and fit notes.

Geometry
Specs
Build
Frame

Wazoo 27.5+ hardtail MTB. Material: aluminium alloy. BSA bottom bracket. QR 141 mm dropout. Smooth welding

BB Standard: BSA, Threaded

Fork

SR Suntour SF18-XCM34. 130 mm travel. 15x110 mm

Travel: 130mm

Spring Type: Coil

Bottom Bracket

BSA

Headset

Tapered 1-1/8 - 1-1/2. Internal

Stem

Aluminium alloy, ⌀31.8 mm, 45 mm, 3deg

Handlebar

Aluminium alloy, ⌀31.8 mm, 20 mm rise, 6deg. 760 mm width (S). 780 mm width (M, L, XL)

Saddle

WTB Volt Medium. Steel rails

Seatpost

Aluminium alloy, ⌀31.6 mm. 350 mm length (S). 400 mm length (M, L, XL)

Type: Rigid

Pedals

FPD NWL-221. Aluminium alloy. Flat with retention pins

Grips

Velo, lock-on, black

Groupset
Rear Derailleur

Shimano RD-M3100-SGS

Front Derailleur

Shimano FD-M3120-M, Side Swing

Crank

Shimano FC-MT101-2. 2x 36-22t. 170 mm (S, M, L)

Shifters

Shimano SL-M3010-L. Shimano SL-M3000-R

Cassette

Shimano CS-HG200-9. 9 speed. 11-36t

Chain

KMC X9

Brakes

Clarks Clout. Hydraulic brake

Type: Hydraulic Disc

Brake Levers

Clarks Clout. Hydraulic brake

Wheels
Rims

584/27.5 aluminium alloy, double wall. 32H. Tubeless compatible 18 mm height

Spokes

Steel

Front Hub

Aluminium alloy, 15x110, 32H, 6 bolts (F). Aluminium alloy, QR141, 32H, 6 bolts (R)

Rear Hub

Aluminium alloy, 15x110, 32H, 6 bolts (F). Aluminium alloy, QR141, 32H, 6 bolts (R)

Tires

Maxxis Rekon+ 27.5x2.6. Foldable. 60TPI

Disc Rotors

Clarks Clout. 180 mm (F). Clarks Clout. 160 mm (R)
